Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX222
BD DRIVER
R110 1-216-295-00 SHORT 0
R112 1-216-025-11 RES-CHIP 100 5% 1/10W
R123 1-216-073-00 RES-CHIP 10K 5% 1/10W
R124 1-216-097-11 RES-CHIP 100K 5% 1/10W
R125 1-216-033-00 METAL CHIP 220 5% 1/10W
R126 1-216-033-00 METAL CHIP 220 5% 1/10W
R127 1-216-033-00 METAL CHIP 220 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R135 1-216-295-00 SHORT 0
R136 1-216-295-00 SHORT 0
R137 1-216-295-00 SHORT 0
R138 1-216-295-00 SHORT 0
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R145 1-216-121-11 RES-CHIP 1M 5% 1/10W
R146 1-216-121-11 RES-CHIP 1M 5% 1/10W
R147 1-216-041-00 METAL CHIP 470 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-003-11 RES-CHIP 12 5% 1/10W
R150 1-216-073-00 RES-CHIP 10K 5% 1/10W
R154 1-216-025-11 RES-CHIP 100 5% 1/10W
R155 1-216-025-11 RES-CHIP 100 5% 1/10W
R156 1-216-025-11 RES-CHIP 100 5% 1/10W
R157 1-216-025-11 RES-CHIP 100 5% 1/10W
R158 1-216-073-00 RES-CHIP 10K 5% 1/10W
R159 1-216-089-00 RES-CHIP 47K 5% 1/10W
R161 1-216-295-00 SHORT 0
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-11 RES-CHIP 100 5% 1/10W
R172 1-216-025-11 RES-CHIP 100 5% 1/10W
R173 1-216-025-11 RES-CHIP 100 5% 1/10W
R175 1-216-025-11 RES-CHIP 100 5% 1/10W
R180 1-216-097-11 RES-CHIP 100K 5% 1/10W
R181 1-216-100-00 RES-CHIP 130K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R184 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R185 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R186 1-216-081-00 METAL CHIP 22K 5% 1/10W
R187 1-216-081-00 METAL CHIP 22K 5% 1/10W
R188 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R189 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R190 1-216-081-00 METAL CHIP 22K 5% 1/10W
R191 1-216-081-00 METAL CHIP 22K 5% 1/10W
R192 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R193 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R194 1-216-295-00 SHORT 0
R203 1-216-025-11 RES-CHIP 100 5% 1/10W
R204 1-216-025-11 RES-CHIP 100 5% 1/10W
R205 1-216-025-11 RES-CHIP 100 5% 1/10W
R206 1-216-295-00 SHORT 0
R210 1-216-295-00 SHORT 0
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
******************************************************
1-675-912-14 DRIVER BOARD
************
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-15 DIODE MTZJ-T-77-3.9A
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
******************************************************
1-681-447-11 KEY BOARD
*********
< DIODE >
D707 8-719-058-04 DIODE SEL5223S-TP15 (REC PAUSE/START)
D708 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D709 8-719-057-97 DIODE SEL5923A-TP15 (KARAOKE PON)
D711 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
< TRANSISTOR >
Q707 8-729-900-80 TRANSISTOR DTC114ES
Q708 8-729-900-80 TRANSISTOR DTC114ES
Q709 8-729-900-80 TRANSISTOR DTC114ES
Q712 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-413-11 CARBON 470 5% 1/4W
R704 1-249-414-11 CARBON 560 5% 1/4W
R705 1-249-415-11 CARBON 680 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W
R707 1-249-418-11 CARBON 1.2K 5% 1/4W
R708 1-249-420-11 CARBON 1.8K 5% 1/4W
R709 1-249-422-11 CARBON 2.7K 5% 1/4W
R710 1-247-843-11 CARBON 3.3K 5% 1/4W
R711 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-410-11 CARBON 270 5% 1/4W
R714 1-249-411-11 CARBON 330 5% 1/4W
R715 1-249-413-11 CARBON 470 5% 1/4W
R716 1-249-414-11 CARBON 560 5% 1/4W
R717 1-249-415-11 CARBON 680 5% 1/4W
R718 1-249-417-11 CARBON 1K 5% 1/4W
R719 1-249-418-11 CARBON 1.2K 5% 1/4W
R720 1-249-420-11 CARBON 1.8K 5% 1/4W
R721 1-249-422-11 CARBON 2.7K 5% 1/4W
R726 1-249-410-11 CARBON 270 5% 1/4W
R727 1-249-411-11 CARBON 330 5% 1/4W
R728 1-249-413-11 CARBON 470 5% 1/4W
R729 1-249-414-11 CARBON 560 5% 1/4W
R730 1-249-415-11 CARBON 680 5% 1/4W
R731 1-249-417-11 CARBON 1K 5% 1/4W
R732 1-249-418-11 CARBON 1.2K 5% 1/4W
KEY
