Sony HCD-VX7A - Printed Wiring Board - BD Board

HCD-VX5A/VX5AJ/VX7A
– 33 – – 34 –
7-7. PRINTED WIRING BOARD – BD Board – • See page 32 for Circuit Boards Location.
• Semiconductor
Location
(Side A)
Ref. No. Location
IC104 F-3
Q101 F-6
• Semiconductor
Location
(Side B)
Ref. No. Location
IC101 E-4
IC102 C-5
IC103 E-6
(Page 42)
