7-31. IC PIN FUNCTION DESCRIPTION
• MAIN BOARD IC501 M30622MA-A09FP (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1 STK-MUTE O
Power amplifier on/off selection signal output terminal “L”: standby mode, “H”: on
2 POWER O
Power on/off control signal output for the audio system (+5V) and deck, panel, audio system
(+7V) “L”: standby mode, “H”: power on
3 F-RELAY O
Relay drive signal output for the speaker protect “H”: relay on
4 R-RELAY O
Relay drive signal output for the speaker protect “H”: relay on Not used (open)
5 CD-POWER O
Power on/off control signal output for the CD/video CD section
“L”: standby mode, “H”: power on
6 LINE-MUTE O
Line muting on/off control signal output terminal “L”: muting on
7 DBFB-H/L O
DBFB normal/high selection signal output to the M62493FP (IC101)
“L”: DBFB high, “H”: DBFB low
8
BYTE
I
External data bus line byte selection signal input terminal Fixed at “L” in this set
9 CNVSS —
Ground terminal
10 XC-IN I
Sub system clock input terminal (32.768 kHz)
11 XC-OUT O
Sub system clock output terminal (32.768 kHz)
12 RESET I
System reset signal input from the reset signal generator (IC502) “L”: reset
For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H”
13 X-OUT O
Main system clock output terminal (16 MHz)
14 VSS —
Ground terminal
15 X-IN I
Main system clock input terminal (16 MHz)
16 VCC —
Power supply terminal (+5V)
17
NMI
I
Non-maskable interrupt input terminal Fixed at “H” in this set
18 WAKE UP I
Wakeup control signal input from the fluorescent indicator tube driver (IC601) “H” active
19 SCOR
I Subcode sync (S0+S1) detection signal input terminal Not used (fixed at “L”)
20 RDS-INT I
Serial data transfer clock signal input terminal Not used (fixed at “L”)
21 RDS-DATA I
Serial data input terminal Not used (fixed at “L”)
22 AC-CUT I
AC off detection signal input from the reset signal generator (IC502) “L”: AC cut checked
23 PL-CLK O
Serial data transfer clock signal output to the pro-logic circuit Not used (open)
24 PL-DATA O
Serial data output to the pro-logic circuit Not used (open)
25 PL-LAT O
Serial data latch pulse output to the pro-logic circuit Not used (open)
26 TIMER LED O
LED drive signal output of the TIMER SELECT indicator (D632) “H”: LED on
27 PROTECTOR I
Protect on/off detection signal input from the speaker protect circuit
“L”: protect on, “H”: protect off
28
NCO
O
Not used (open)
29 IIC-CLK I/O
Communication data reading clock signal input or transfer clock signal output with the CD
mechanism controller (IC502) and fluorescent indicator tube driver (IC601)
30 IIC-DATA I/O
Communication data bus with the CD mechanism controller (IC502) and fluorescent indicator
tube driver (IC601)
31 NCO O
Not used (open)
32
SQ-DATA
I
Subcode Q data input terminal Not used (fixed at “L”)
33
SQ-CLK
O
Subcode Q data reading clock signal output terminal Not used (open)
34 SW MODE O
Not used (open)
35
CD-DATA
O
Serial data output terminal Not used (open)
36 RY-SW I
Connection detect signal input of the headphone jack (J701)
“L”: no connected, “H”: headphone connected
37 CD-CLK O
Serial data transfer clock signal output terminal Not used (open)
38 493-LATCH O
Serial data latch pulse output to the M62493FP (IC101)
39 STBY LED O
LED drive signal output of the I/u indicator (D754) “H”: LED on (standby mode)
