Sony HCD-VX7A - SECTION 3 DISASSEMBLY; Unit Disassembly Procedures

– 10 –
COVER
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
3 two screws
(case 3TP2) (3
× 8)
2 screw
(case 3TP2) (3
× 12)
1 three screws
(BVTP3
× 8)
6 cover
2 screw
(case 3TP2) (3
× 12)
3 two screws
(case 3TP2) (3
× 8)
5
4
4
LOADING PANEL ASS’Y
3 loading panel ass’y
2 Pull-out
the disc tray.
1 Turn the cam-in the
direction of the arrow
A .
A
