– 11 –
FRONT PANEL SECTION
VIDEO BOARD, CD MECHANISM DECK SECTION (CDM38L-5BD34L)
2
screw
(BVTT3
×
6
2
screw
(BVTT3
×
6)
4
screw
(BVTT3
×
10)
6
front panel section
4
screw
(BVTP3
×
10)
5
two screws
(BVTT3
×
6)
3
lug
3
two lugs
1
wire (flat type)
(15 core) (32 cm) (CN303)
1
wire (flat type) (17 core)
(CN304)
1
wire (flat type)
(23 core) (23 cm) (CN501)
6
screw
(BVTP3
×
10)
7
two screws
(BVTP3
×
8)
5
chassis
4
screw
(BVTP3
×
8)
9
two connectors
(CN392, 393)
2
two screws
(BVTP3
×
8)
6
screw
(BVTP3
×
10)
8
Remove the CD mechanism
deck (CDM38L-5BD34L)
in the direction of arrows
A
–
B
.
B
A
1
wire (flat type)
(13 core) (17 cm) (CN503)
1
wire (flat type)
(23 core) (18 cm)
(CN501)
2
screw
(BVTP3
×
8)
3
VIDEO
board
