– 75 –
• Waveforms
– BD Board –
2.6 Vp-p
7.5
µ
s
1 IC101 @∞ (MDP)
0.2 mVp-p
2 IC101 #ª (FE) (CD Play mode)
0.5 mVp-p
3 IC101 $¡ (TE) (CD Play mode)
1.3 Vp-p
4 IC101 $£ (RFDC) (CD Play mode)
1.3 Vp-p
5 IC101 %º (RFAC) (CD Play mode)
5.2 Vp-p
22.7
µ
s
6 IC101 ^∞ (LRCK)
5.2 Vp-p
474 ns
7 IC101 ^¶ (BCLK)
5.2 Vp-p
16.9344 MHz
8 IC101 &¡ (XTAI)
9 IC103 !§ (RFO) (CD Play mode)
1.3 Vp-p
2 IC501 !∞ (XIN)
– MAIN Board –
1 IC501 0 (XC-IN)
2.2 Vp-p
16 MHz
– PANEL Board –
1 IC601 &™ (XOUT)
4.7 Vp-p
12.5 MHz
– SURROUND Board –
1 IC1201 @£ (LC-INB)
5.9 Vp-p
105 ns
