– 5 –
NOTE FOR INSTALLATION (ROTARY ENCODER)
1
Remove the Case.
3
Pull-out the disc tray.
2
Turn the cam to the
direction of arrow.
HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH TURNS’ OFF.
BU cam
Groove
Section A
Note:When attaching the Base unit, Insert th
section A into the groove of BU cam.
Note:When attaching the BU cam,
engage the Rotary encoder
switch as shown in the figure.
