– 105 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R133 1-247-807-31 CARBON 100 5% 1/4W
R141 1-249-433-11 CARBON 22K 5% 1/4W
R142 1-249-433-11 CARBON 22K 5% 1/4W
R143 1-249-417-11 CARBON 1K 5% 1/4W
R144 1-249-441-11 CARBON 100K 5% 1/4W
R145 1-247-903-00 CARBON 1M 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W
R152 1-249-417-11 CARBON 1K 5% 1/4W
R153 1-249-417-11 CARBON 1K 5% 1/4W
R161 1-249-429-11 CARBON 10K 5% 1/4W
R162 1-247-895-00 CARBON 470K 5% 1/4W
R163 1-247-894-11 CARBON 430K 5% 1/4W
R164 1-249-415-11 CARBON 680 5% 1/4W
R165 1-249-433-11 CARBON 22K 5% 1/4W
R166 1-247-887-00 CARBON 220K 5% 1/4W
R167 1-249-429-11 CARBON 10K 5% 1/4W
R168 1-249-437-11 CARBON 47K 5% 1/4W
R169 1-249-421-11 CARBON 2.2K 5% 1/4W
R170 1-249-441-11 CARBON 100K 5% 1/4W
R171 1-249-429-11 CARBON 10K 5% 1/4W
R178 1-249-421-11 CARBON 2.2K 5% 1/4W
R190 1-249-441-11 CARBON 100K 5% 1/4W
R196 1-249-417-11 CARBON 1K 5% 1/4W
R197 1-249-441-11 CARBON 100K 5% 1/4W
R198 1-249-417-11 CARBON 1K 5% 1/4W
R199 1-249-429-11 CARBON 10K 5% 1/4W
R201 1-247-888-11 CARBON 240K 5% 1/4W
R202 1-247-903-00 CARBON 1M 5% 1/4W
R211 1-249-441-11 CARBON 100K 5% 1/4W
R212 1-249-441-11 CARBON 100K 5% 1/4W
R251 1-247-888-11 CARBON 240K 5% 1/4W
R252 1-247-903-00 CARBON 1M 5% 1/4W
R261 1-249-441-11 CARBON 100K 5% 1/4W
R262 1-249-441-11 CARBON 100K 5% 1/4W
R301 1-249-435-11 CARBON 33K 5% 1/4W
R302 1-249-421-11 CARBON 2.2K 5% 1/4W
R303 1-247-807-31 CARBON 100 5% 1/4W
R304 1-247-807-31 CARBON 100 5% 1/4W
R305 1-249-421-11 CARBON 2.2K 5% 1/4W
R306 1-249-428-11 CARBON 8.2K 5% 1/4W
R307 1-249-428-11 CARBON 8.2K 5% 1/4W
R308 1-249-425-11 CARBON 4.7K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R311 1-247-903-00 CARBON 1M 5% 1/4W
R312 1-247-884-11 CARBON 160K 5% 1/4W
R313 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-429-11 CARBON 10K 5% 1/4W
R316 1-249-432-11 CARBON 18K 5% 1/4W
R317 1-249-429-11 CARBON 10K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-247-893-11 CARBON 390K 5% 1/4W
R321 1-249-422-11 CARBON 2.7K 5% 1/4W
R322 1-249-428-11 CARBON 8.2K 5% 1/4W
R324 1-247-876-11 CARBON 75K 5% 1/4W
R325 1-247-876-11 CARBON 75K 5% 1/4W
R326 1-249-437-11 CARBON 47K 5% 1/4W
R327 1-249-437-11 CARBON 47K 5% 1/4W
R328 1-249-437-11 CARBON 47K 5% 1/4W
MAIN
R329 1-249-417-11 CARBON 1K 5% 1/4W
R330 1-249-425-11 CARBON 4.7K 5% 1/4W
R331 1-249-425-11 CARBON 4.7K 5% 1/4W
R332 1-249-415-11 CARBON 680 5% 1/4W
R333 1-249-421-11 CARBON 2.2K 5% 1/4W
R334 1-249-415-11 CARBON 680 5% 1/4W
R335 1-249-421-11 CARBON 2.2K 5% 1/4W
R336 1-249-437-11 CARBON 47K 5% 1/4W
R337 1-249-417-11 CARBON 1K 5% 1/4W
R338 1-249-411-11 CARBON 330 5% 1/4W
R339 1-249-437-11 CARBON 47K 5% 1/4W
R340 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-411-11 CARBON 330 5% 1/4W
R342 1-249-437-11 CARBON 47K 5% 1/4W
R343 1-249-417-11 CARBON 1K 5% 1/4W
R351 1-249-435-11 CARBON 33K 5% 1/4W
R352 1-249-421-11 CARBON 2.2K 5% 1/4W
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-247-807-31 CARBON 100 5% 1/4W
R355 1-249-421-11 CARBON 2.2K 5% 1/4W
R356 1-249-428-11 CARBON 8.2K 5% 1/4W
R357 1-249-428-11 CARBON 8.2K 5% 1/4W
R358 1-249-425-11 CARBON 4.7K 5% 1/4W
R359 1-249-435-11 CARBON 33K 5% 1/4W
R391 1-249-422-11 CARBON 2.7K 5% 1/4W
R392 1-249-422-11 CARBON 2.7K 5% 1/4W
R393 1-249-426-11 CARBON 5.6K 5% 1/4W
R394 1-249-426-11 CARBON 5.6K 5% 1/4W
R395 1-249-435-11 CARBON 33K 5% 1/4W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-425-11 CARBON 4.7K 5% 1/4W
R409 1-249-441-11 CARBON 100K 5% 1/4W
R410 1-249-421-11 CARBON 2.2K 5% 1/4W
! R411 1-215-894-11 METAL OXIDE 2.2K 5% 2W F
R413 1-249-402-11 CARBON 56 5% 1/4W
R414 1-249-417-11 CARBON 1K 5% 1/4W
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-437-11 CARBON 47K 5% 1/4W
R417 1-249-417-11 CARBON 1K 5% 1/4W
R421 1-260-089-11 CARBON 150 5% 1/2W
R422 1-260-089-11 CARBON 150 5% 1/2W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-249-433-11 CARBON 22K 5% 1/4W
R435 1-249-435-11 CARBON 33K 5% 1/4W
R437 1-249-429-11 CARBON 10K 5% 1/4W
R438 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W
R440 1-249-433-11 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-417-11 CARBON 1K 5% 1/4W
R471 1-260-089-11 CARBON 150 5% 1/2W
R472 1-260-089-11 CARBON 150 5% 1/2W
R473 1-249-402-11 CARBON 56 5% 1/4W
R474 1-249-417-11 CARBON 1K 5% 1/4W
R481 1-260-089-11 CARBON 150 5% 1/2W
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
