ā 111 ā
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C1211 1-126-964-11 ELECT 10uF 20% 50V
C1212 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1213 1-126-934-11 ELECT 220uF 20% 10V
C1214 1-136-167-00 FILM 0.15uF 5% 50V
C1215 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C1216 1-136-167-00 FILM 0.15uF 5% 50V
C1217 1-124-252-00 ELECT 0.33uF 20% 50V
C1218 1-126-934-11 ELECT 220uF 20% 10V
C1219 1-126-964-11 ELECT 10uF 20% 50V
C1220 1-126-964-11 ELECT 10uF 20% 50V
C1221 1-162-216-31 CERAMIC 51PF 5% 50V
< CONNECTOR >
* CN1201 1-564-788-11 PIN, CONNECTOR 8P
< IC >
IC1201 8-759-579-61 IC LV1150
< COIL >
L1201 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R1201 1-247-807-31 CARBON 100 5% 1/4W
R1203 1-249-441-11 CARBON 100K 5% 1/4W
R1204 1-249-441-11 CARBON 100K 5% 1/4W
R1205 1-249-417-11 CARBON 1K 5% 1/4W
R1206 1-249-441-11 CARBON 100K 5% 1/4W
R1207 1-249-441-11 CARBON 100K 5% 1/4W
**************************************************************
* 1-672-369-11 TRANSFORMER BOARD
*******************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C952 1-162-306-11 CERAMIC 0.01uF 30% 16V
C971 1-128-563-11 ELECT 100uF 20% 100V
C972 1-126-960-11 ELECT 1uF 20% 50V
C973 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P
* CN952 1-564-527-11 PLUG, CONNECTOR 12P
CN953 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-986-60 DIODE HZS27-3LTA
D973 8-719-109-63 DIODE MTZJ-T-72-3.0B
< FUSE >
! F951 1-532-506-31 FUSE T6.3AL/250V
(EXCEPT VX5A: TH/VX7A: TH)
! F961 1-532-505-31 FUSE T5AL/250V
! F962 1-532-505-31 FUSE T5AL/250V
! F963 1-532-506-31 FUSE T6.3AL/250V
! F964 1-532-506-31 FUSE T6.3AL/250V
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R971 1-216-456-00 METAL OXIDE 820 5% 2W F
R972 1-249-429-11 CARBON 10K 5% 1/4W
R973 1-249-429-11 CARBON 10K 5% 1/4W
R974 1-247-807-31 CARBON 100 5% 1/4W
R975 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
! S951 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(EXCEPT VX5A: TH/VX7A: TH)
< TRANSFORMER >
! T951 1-433-561-21 TRANSFORMER, POWER (VX7A)
! T951 1-433-565-11 TRANSFORMER, POWER (VX5A)
! T951 1-433-565-21 TRANSFORMER, POWER (VX5AJ)
**************************************************************
A-4724-823-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C301 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C302 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C303 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C304 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C305 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C306 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C311 1-216-295-00 SHORT 0
C313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C318 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C319 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C403 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C404 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C405 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C406 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C409 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C410 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C411 1-165-319-11 CERAMIC CHIP 0.1uF 50V
SURROUND TRANSFORMER VIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
