– 110 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S643 1-762-875-21 SWITCH, KEYBOARD (^)
S644 1-762-875-21 SWITCH, KEYBOARD (p)
S645 1-762-875-21 SWITCH, KEYBOARD (B:()
S646 1-762-875-21 SWITCH, KEYBOARD (B:9)
S647 1-762-875-21 SWITCH, KEYBOARD (A:()
S648 1-762-875-21 SWITCH, KEYBOARD (A:9)
S649 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S650 1-762-875-21 SWITCH, KEYBOARD (CD LOOP)
S651 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S652 1-762-875-21 SWITCH, KEYBOARD (CLOCK/TIME SET)
S653 1-762-875-21 SWITCH, KEYBOARD (TIME SELECT)
S654 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S655 1-762-875-21 SWITCH, KEYBOARD (REPEAT STERO/MONO)
S656 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE DOLBY ON)
S657 1-762-875-21 SWITCH, KEYBOARD
(EDIT DIRECTION TUNER MEMORY)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
X602 1-767-353-11 VIBRATOR, CERAMIC (4.09MHz)
**************************************************************
* 1-658-576-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
**************************************************************
A-4419-159-A SURROUND BOARD, COMPLETE
************************
< CAPACITOR >
C1201 1-162-203-31 CERAMIC 15PF 5% 50V
C1202 1-162-216-31 CERAMIC 51PF 5% 50V
C1203 1-162-282-31 CERAMIC 100PF 10% 50V
C1204 1-162-283-31 CERAMIC 120PF 10% 50V
C1205 1-162-279-31 CERAMIC 75PF 10% 50V
C1206 1-136-165-00 FILM 0.1uF 5% 50V
C1207 1-162-306-11 CERAMIC 0.01uF 20% 16V
C1208 1-126-934-11 ELECT 220uF 20% 10V
C1209 1-136-165-00 FILM 0.1uF 5% 50V
C1210 1-126-964-11 ELECT 10uF 20% 50V
C1211 1-126-964-11 ELECT 10uF 20% 50V
C1212 1-162-306-11 CERAMIC 0.01uF 20% 16V
C1213 1-126-934-11 ELECT 220uF 20% 10V
C1214 1-136-167-00 FILM 0.15uF 5% 50V
C1215 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C1216 1-136-167-00 FILM 0.15uF 5% 50V
C1217 1-124-252-00 ELECT 0.33uF 20% 50V
C1218 1-126-934-11 ELECT 220uF 20% 10V
C1219 1-126-964-11 ELECT 10uF 20% 50V
C1220 1-126-964-11 ELECT 10uF 20% 50V
C1221 1-162-216-31 CERAMIC 51PF 5% 50V
< CONNECTOR >
CN1201 1-564-788-11 PIN, CONNECTOR 8P
< IC >
IC1201 8-759-579-61 IC LV1150
< COIL >
L1201 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R1201 1-247-807-31 CARBON 100 5% 1/4W
R1203 1-249-441-11 CARBON 100K 5% 1/4W
R1204 1-249-441-11 CARBON 100K 5% 1/4W
R1205 1-249-417-11 CARBON 1K 5% 1/4W F
R1206 1-249-441-11 CARBON 100K 5% 1/4W
R1207 1-249-441-11 CARBON 100K 5% 1/4W
**************************************************************
* 1-672-474-11 TRANS BOARD
***********
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
C972 1-126-960-11 ELECT 1uF 20% 50V
C973 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
* CN901 1-564-527-11 PLUG, CONNECTOR 12P
CN902 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
CN951 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-056-97 DIODE UDZ-TE-17-27B
D973 8-719-056-74 DIODE UDZ-TE-17-3.0B
< FUSE >
! F951 1-532-506-31 FUSE (T6.3AL/250V)(EXCEPT TH)
! F952 1-532-465-31 FUSE (T3.15AL/250V)(EXCEPT TH)
! F953 1-532-465-31 FUSE (T3.15AL/250V)
! F961 1-532-505-31 FUSE (T5AL/250V)
! F962 1-532-505-31 FUSE (T5AL/250V)
< FUSE HOLDER >
FH951 1-533-233-21 HOLDER, FUSE
FH952 1-533-233-21 HOLDER, FUSE
FH953 1-533-233-21 HOLDER, FUSE
FH954 1-533-233-21 HOLDER, FUSE
FH955 1-533-233-21 HOLDER, FUSE
FH956 1-533-233-21 HOLDER, FUSE
FH961 1-533-233-21 HOLDER, FUSE
FH962 1-533-233-21 HOLDER, FUSE
FH963 1-533-233-21 HOLDER, FUSE
FH964 1-533-233-21 HOLDER, FUSE
SURROUND
SENSOR
PANEL
TRANS
