Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
! R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R971 1-216-455-11 METAL OXIDE 560 5% 2W F
R972 1-216-085-00 METAL CHIP 33K 5% 1/10W
R973 1-216-073-00 METAL CHIP 10K 5% 1/10W
R974 1-216-025-91 RES,CHIP 100 5% 1/10W
R975 1-216-025-91 RES,CHIP 100 5% 1/10W
R976 1-216-085-00 METAL CHIP 33K 5% 1/10W
R977 1-216-085-00 METAL CHIP 33K 5% 1/10W
< SWITCH >
! S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(EXCEPT VX8:TH)
< TRANSFORMER >
! T951 1-433-556-11 TRANSFORMER, POWER
**************************************************************
A-4724-727-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C301 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C302 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C303 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C304 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C305 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C306 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C311 1-216-295-91 SHORT 0
C313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C318 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C319 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C403 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C404 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C405 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C406 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C409 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C410 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C411 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C412 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C413 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C452 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C501 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C503 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C550 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C551 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C552 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C553 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C555 1-124-779-00 ELECT CHIP 10uF 20% 16V
C556 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C559 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C560 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C561 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C562 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C563 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C564 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C568 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C569 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C570 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C571 1-128-065-11 ELECT CHIP 68MF 20% 10V
C573 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C574 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C576 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C577 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CN501 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN503 1-779-416-11 CONNECTOR,FFC(LIF(NON-ZIF))13P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
VIDEOTRANS
To Next Page
