60
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
BD
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-839-11 METAL CHIP 33K 5% 1/16W
R105 1-216-821-11 METAL CHIP 1K 5% 1/16W
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R109 1-216-857-11 METAL CHIP 1M 5% 1/16W
R111 1-216-846-11 METAL CHIP 120K 5% 1/16W
R114 1-218-745-11 RES-CHIP 160K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/16W
R118 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R131 1-216-813-11 METAL CHIP 220 5% 1/16W
R143 1-216-839-11 METAL CHIP 33K 5% 1/16W
R144 1-216-839-11 METAL CHIP 33K 5% 1/16W
R147 1-218-701-11 RES-CHIP 2.4K 5% 1/10W
R148 1-216-797-11 METAL CHIP 10 5% 1/16W
R149 1-216-797-11 METAL CHIP 10 5% 1/16W
R158 1-216-838-11 METAL CHIP 27K 5% 1/16W
R159 1-216-838-11 METAL CHIP 27K 5% 1/16W
R162 1-216-845-11 METAL CHIP 100K 5% 1/16W
R171 1-216-837-11 METAL CHIP 22K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-837-11 METAL CHIP 22K 5% 1/16W
R181 1-216-837-11 METAL CHIP 22K 5% 1/16W
R182 1-216-837-11 METAL CHIP 22K 5% 1/16W
R183 1-216-837-11 METAL CHIP 22K 5% 1/16W
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-839-11 METAL CHIP 33K 5% 1/16W
R192 1-216-839-11 METAL CHIP 33K 5% 1/16W
R193 1-216-846-11 METAL CHIP 120K 5% 1/16W
R194 1-216-839-11 METAL CHIP 33K 5% 1/16W
R195 1-216-849-11 METAL CHIP 220K 5% 1/16W
R196 1-216-819-11 METAL CHIP 680 5% 1/16W
R198 1-216-864-11 METAL CHIP 0 5% 1/16W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-238-602-11 RES, ADJ, CARBON 47K (E-F BALANCE)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
******************************************************
1-683-452-11 CD-L BOARD
*********
< CONNECTOR >
* CN704 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< RESISTOR >
R771 1-249-419-11 CARBON 1.5K 5% 1/4W F
R772 1-249-419-11 CARBON 1.5K 5% 1/4W F
R773 1-249-421-11 CARBON 2.2K 5% 1/4W F
R774 1-247-843-11 CARBON 3.3K 5% 1/4W
R775 1-249-425-11 CARBON 4.7K 5% 1/4W F
R776 1-249-427-11 CARBON 6.8K 5% 1/4W F
R777 1-249-429-11 CARBON 10K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
< SWITCH >
S741 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S742 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S743 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S744 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S745 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
S746 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S747 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S748 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S749 1-762-875-21 SWITCH, KEYBOARD (EDIT)
******************************************************
1-683-453-11 CD-R BOARD
**********
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
< DIODE >
D700 8-719-056-13 DIODE SML79423C-TP15 (GX )
< RESISTOR >
R782 1-247-843-11 CARBON 3.3K 5% 1/4W
R783 1-249-425-11 CARBON 4.7K 5% 1/4W F
R784 1-249-427-11 CARBON 6.8K 5% 1/4W F
R790 1-247-791-91 CARBON 22 5% 1/4W
R791 1-247-791-91 CARBON 22 5% 1/4W
< SWITCH >
S752 1-762-875-21 SWITCH, KEYBOARD (GX )
S753 1-762-875-21 SWITCH, KEYBOARD (x )
S754 1-762-875-21 SWITCH, KEYBOARD (m )
S755 1-762-875-21 SWITCH, KEYBOARD (M )
S763 1-473-393-11 ENCODER, ROTARY ( . AMS > )
******************************************************
1-684-683-11 D-SW BOARD
**********
< CAPACITOR >
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
< SWITCH >
S740 1-762-587-11 SWITCH, PUSH (1 KEY) (DOOR)
******************************************************
1-683-454-11 FRONT INPUT BOARD
****************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
CD-L CD-R D-SW FRONT INPUT
