61
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
LED
C703 1-126-960-11 ELECT 1uF 20% 50V
C704 1-164-159-21 CERAMIC 0.1uF 50V
C705 1-162-282-31 CERAMIC 100PF 10% 50V
< FILTER >
FL730 1-424-228-11 FILTER, NOISE
< JACK >
J804 1-815-310-11 JACK 3P (GAME INPUT)
< RESISTOR >
R721 1-249-437-11 CARBON 47K 5% 1/4W
R722 1-249-417-11 CARBON 1K 5% 1/4W F
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-247-804-11 CARBON 75 5% 1/4W
R725 1-249-417-11 CARBON 1K 5% 1/4W F
******************************************************
1-683-450-11 HEADPHONE BOARD
***************
< CAPACITOR >
C891 1-162-294-31 CERAMIC 0.001uF 10% 50V
C892 1-162-294-31 CERAMIC 0.001uF 10% 50V
C893 1-164-159-21 CERAMIC 0.1uF 50V
< JACK >
J891 1-770-226-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R891 1-247-807-31 CARBON 100 5% 1/4W
******************************************************
*
1-659-059-13 LED BOARD
*********
< DIODE >
D201 8-719-032-98 DIODE SEL5820A (DISC No.)
< TRANSISTOR >
Q201 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R201 1-249-433-11 CARBON 22K 5% 1/4W
R202 1-249-411-11 CARBON 330 5% 1/4W
R203 1-249-437-11 CARBON 47K 5% 1/4W
******************************************************
A-4440-764-A MAIN BOARD, COMPLETE (XGR60:AR,E,E51)
A-4676-330-A MAIN BOARD, COMPLETE (XGR60:MX)
A-4727-645-A MAIN BOARD, COMPLETE (XGR6)
*******************
4-875-327-31 HEAT SINK
4-948-236-21 CUSHION (107)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C72 1-136-169-00 FILM 0.22uF 5% 50V
C73 1-136-169-00 FILM 0.22uF 5% 50V
C110 1-126-795-11 ELECT 10uF 20% 50V
C111 1-126-795-11 ELECT 10uF 20% 50V
C112 1-126-795-11 ELECT 10uF 20% 50V
C113 1-126-795-11 ELECT 10uF 20% 50V
C114 1-126-795-11 ELECT 10uF 20% 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C116 1-130-487-00 MYLAR 0.022uF 5% 50V
C117 1-130-487-00 MYLAR 0.022uF 5% 50V
C118 1-126-795-11 ELECT 10uF 20% 50V
C119 1-130-491-00 MYLAR 0.047uF 5% 50V
C120 1-130-479-00 MYLAR 0.0047uF 5% 50V
C121 1-126-795-11 ELECT 10uF 20% 50V
C122 1-136-171-00 FILM 0.33uF 5% 50V
C123 1-136-171-00 FILM 0.33uF 5% 50V
C124 1-126-961-11 ELECT 2.2uF 20% 50V
C131 1-126-795-11 ELECT 10uF 20% 50V
C132 1-125-972-91 ELECT 100uF 20% 16V
C133 1-126-795-11 ELECT 10uF 20% 50V
C134 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C135 1-124-589-11 ELECT 47uF 20% 16V
C136 1-126-964-11 ELECT 10uF 20% 50V
C137 1-162-967-11 CERAMIC CHIP 3300pF 10% 50V
C138 1-162-967-11 CERAMIC CHIP 3300pF 10% 50V
C160 1-126-795-11 ELECT 10uF 20% 50V
C161 1-126-795-11 ELECT 10uF 20% 50V
C162 1-126-795-11 ELECT 10uF 20% 50V
C163 1-126-795-11 ELECT 10uF 20% 50V
C164 1-126-795-11 ELECT 10uF 20% 50V
C165 1-126-795-11 ELECT 10uF 20% 50V
C166 1-130-487-00 MYLAR 0.022uF 5% 50V
C167 1-130-487-00 MYLAR 0.022uF 5% 50V
C168 1-126-795-11 ELECT 10uF 20% 50V
C169 1-130-491-00 MYLAR 0.047uF 5% 50V
C170 1-130-479-00 MYLAR 0.0047uF 5% 50V
C171 1-126-795-11 ELECT 10uF 20% 50V
C172 1-136-171-00 FILM 0.33uF 5% 50V
C173 1-136-171-00 FILM 0.33uF 5% 50V
C174 1-126-961-11 ELECT 2.2uF 20% 50V
C181 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C182 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C183 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C193 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-130-483-00 MYLAR 0.01uF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-126-964-11 ELECT 10uF 20% 50V
C305 1-136-165-00 FILM 0.1uF 5% 50V
C306 1-126-961-11 ELECT 2.2uF 20% 50V
C307 1-126-947-11 ELECT 47uF 20% 16V
C308 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C309 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C310 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C311 1-126-933-11 ELECT 100uF 20% 16V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C321 1-126-964-11 ELECT 10uF 20% 50V
C322 1-135-575-11 MYLAR 120PF 5% 50V
C323 1-135-575-11 MYLAR 120PF 5% 50V
C324 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C325 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C326 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C327 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C328 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C329 1-162-974-11 CERAMIC CHIP 0.01uF 50V
HEADPHONE MAINFRONT INPUT
