Sony HCD-XGR60 - MIC;Guitar, Motor, PA Board Components

66
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
MAIN
R604 1-216-820-11 METAL CHIP 820 5% 1/16W
(XGR6)
R604 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR60)
R605 1-216-854-11 METAL CHIP 560K 5% 1/16W
R606 1-216-841-11 METAL CHIP 47K 5% 1/16W
R607 1-216-821-11 METAL CHIP 1K 5% 1/16W
R608 1-216-845-11 METAL CHIP 100K 5% 1/16W
R609 1-216-033-00 METAL CHIP 220 5% 1/10W
R611 1-216-821-11 METAL CHIP 1K 5% 1/16W
R612 1-216-821-11 METAL CHIP 1K 5% 1/16W
R613 1-216-815-11 METAL CHIP 330 5% 1/16W
R614 1-216-821-11 METAL CHIP 1K 5% 1/16W
R651 1-216-821-11 METAL CHIP 1K 5% 1/16W
R652 1-216-821-11 METAL CHIP 1K 5% 1/16W
R653 1-216-841-11 METAL CHIP 47K 5% 1/16W
R654 1-216-820-11 METAL CHIP 820 5% 1/16W
(XGR6)
R654 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR60)
R655 1-216-854-11 METAL CHIP 560K 5% 1/16W
R656 1-216-841-11 METAL CHIP 47K 5% 1/16W
R657 1-216-821-11 METAL CHIP 1K 5% 1/16W
R658 1-216-845-11 METAL CHIP 100K 5% 1/16W
R701 1-216-821-11 METAL CHIP 1K 5% 1/16W
R702 1-216-845-11 METAL CHIP 100K 5% 1/16W
R703 1-216-821-11 METAL CHIP 1K 5% 1/16W
R704 1-216-845-11 METAL CHIP 100K 5% 1/16W
R705 1-216-833-11 METAL CHIP 10K 5% 1/16W
R706 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R707 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR6,XGR60:MX)
R709 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR6,XGR60:MX)
R710 1-216-845-11 METAL CHIP 100K 5% 1/16W
(XGR6,XGR60:MX)
R722 1-216-804-11 METAL CHIP 39 5% 1/16W
R724 1-216-833-11 METAL CHIP 10K 5% 1/16W
R751 1-216-821-11 METAL CHIP 1K 5% 1/16W
R752 1-216-845-11 METAL CHIP 100K 5% 1/16W
R753 1-216-821-11 METAL CHIP 1K 5% 1/16W
R754 1-216-845-11 METAL CHIP 100K 5% 1/16W
R755 1-216-833-11 METAL CHIP 10K 5% 1/16W
R756 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R757 1-216-841-11 METAL CHIP 47K 5% 1/16W
R758 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR6,XGR60:MX)
R759 1-216-821-11 METAL CHIP 1K 5% 1/16W
(XGR6,XGR60:MX)
R760 1-216-845-11 METAL CHIP 100K 5% 1/16W
(XGR6,XGR60:MX)
R801 1-216-817-11 METAL CHIP 470 5% 1/16W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R803 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R804 1-216-841-11 METAL CHIP 47K 5% 1/16W
R805 1-216-841-11 METAL CHIP 47K 5% 1/16W
R806 1-216-833-11 METAL CHIP 10K 5% 1/16W
R807 1-216-295-00 SHORT 0
R808 1-216-845-11 METAL CHIP 100K 5% 1/16W
R810 1-216-845-11 METAL CHIP 100K 5% 1/16W
R812 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R813 1-216-833-11 METAL CHIP 10K 5% 1/16W
R922 1-216-295-00 SHORT 0
R961 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R962 1-216-837-11 METAL CHIP 22K 5% 1/16W
R963 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-241-765-11 RES, ADJ, CARBON 22K (REC LEVEL (R))
RV321 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (L))
RV322 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (R))
RV351 1-241-765-11 RES, ADJ, CARBON 22K (REC LEVEL (L))
RV391 1-238-599-11 RES, ADJ, CARBON 4.7K (TAPE SPEED
(NORMAL))
RV392 1-238-598-11 RES, ADJ, CARBON 2.2K (TAPE SPEED (HIGH))
< TRANSFORMER >
T331 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
******************************************************
A-4727-633-A MIC/GUITAR BOARD, COMPLETE
***********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C802 1-162-215-31 CERAMIC 47PF 5% 50V
C803 1-126-960-11 ELECT 1uF 20% 50V
C804 1-126-959-11 ELECT 0.47uF 20% 50V
C805 1-162-294-31 CERAMIC 0.001uF 10% 50V
C806 1-162-215-31 CERAMIC 47PF 5% 50V
C810 1-162-286-21 CERAMIC 220PF 10% 50V
C813 1-137-372-11 MYLAR 0.022uF 5% 50V
C814 1-162-215-31 CERAMIC 47PF 5% 50V
C815 1-162-215-31 CERAMIC 47PF 5% 50V
C816 1-126-961-11 ELECT 2.2uF 20% 50V
C817 1-126-961-11 ELECT 2.2uF 20% 50V
C818 1-162-215-31 CERAMIC 47PF 5% 50V
C819 1-162-215-31 CERAMIC 47PF 5% 50V
C821 1-126-947-11 ELECT 47uF 20% 16V
C822 1-126-947-11 ELECT 47uF 20% 16V
C824 1-126-961-11 ELECT 2.2uF 20% 50V
C836 1-162-306-11 CERAMIC 0.01uF 30% 16V
C837 1-126-964-11 ELECT 10uF 20% 50V
C838 1-126-964-11 ELECT 10uF 20% 50V
C880 1-126-961-11 ELECT 2.2uF 20% 50V
C881 1-162-215-31 CERAMIC 47PF 5% 50V
C882 1-162-215-31 CERAMIC 47PF 5% 50V
C884 1-126-961-11 ELECT 2.2uF 20% 50V
< CONNECTOR >
* CN812 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< FILTER >
FL801 1-424-228-11 FILTER, NOISE
< IC >
IC850 8-759-505-55 IC NJM4558L
IC852 8-759-505-55 IC NJM4558L
MIC/GUITAR
