Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
IC853 8-759-505-55 IC NJM4558L
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE) (MIX MIC)
J802 1-770-226-11 JACK (LARGE TYPE) (GUITAR)
< TRANSISTOR >
Q880 8-729-620-05 TRANSISTOR 2SC2603-EF
Q881 8-729-029-86 TRANSISTOR DTC124ESA
Q882 8-729-029-86 TRANSISTOR DTC124ESA
Q883 8-729-029-40 TRANSISTOR DTA124ESA
Q884 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R807 1-249-429-11 CARBON 10K 5% 1/4W
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R850 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-899-11 CARBON 680K 5% 1/4W
R857 1-249-425-11 CARBON 4.7K 5% 1/4W F
R867 1-249-421-11 CARBON 2.2K 5% 1/4W F
R869 1-249-439-11 CARBON 68K 5% 1/4W
R870 1-247-887-00 CARBON 220K 5% 1/4W
R872 1-249-421-11 CARBON 2.2K 5% 1/4W F
R873 1-249-421-11 CARBON 2.2K 5% 1/4W F
R874 1-249-431-11 CARBON 15K 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W F
R877 1-249-411-11 CARBON 330 5% 1/4W
R878 1-249-417-11 CARBON 1K 5% 1/4W F
R879 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-429-11 CARBON 10K 5% 1/4W
R881 1-249-437-11 CARBON 47K 5% 1/4W
R882 1-249-437-11 CARBON 47K 5% 1/4W
R883 1-249-437-11 CARBON 47K 5% 1/4W
R884 1-249-413-11 CARBON 470 5% 1/4W F
R885 1-249-429-11 CARBON 10K 5% 1/4W
R886 1-247-893-11 CARBON 390K 5% 1/4W
R887 1-249-429-11 CARBON 10K 5% 1/4W
R888 1-249-417-11 CARBON 1K 5% 1/4W F
R891 1-247-903-00 CARBON 1M 5% 1/4W
*******************************************************
*
A-4673-765-A MOTOR BOARD, COMPLETE
********************
*
4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP)
******************************************************
A-4727-618-A PA BOARD, COMPLETE (XGR60)
A-4727-641-A PA BOARD, COMPLETE (XGR6)
*****************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C412 1-162-306-11 CERAMIC 0.01uF 30% 16V
C413 1-162-306-11 CERAMIC 0.01uF 30% 16V
C432 1-126-933-11 ELECT 100uF 20% 16V
C433 1-126-962-11 ELECT 3.3uF 20% 50V
(XGR60)
C433 1-126-961-11 ELECT 2.2uF 20% 50V
(XGR6)
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-162-290-31 CERAMIC 470PF 10% 50V
C803 1-162-286-21 CERAMIC 220PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C808 1-137-749-11 MYLAR 0.1uF 100V
C809 1-137-749-11 MYLAR 0.1uF 100V
C810 1-128-562-11 ELECT 47uF 20% 100V
(XGR60)
C810 1-128-578-11 ELECT 1uF 20% 100V
(XGR6)
C811 1-130-491-00 MYLAR 0.047uF 5% 50V
C812 1-130-491-00 MYLAR 0.047uF 5% 50V
C813 1-162-306-11 CERAMIC 0.01uF 30% 16V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-126-959-11 ELECT 0.47uF 20% 50V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-11 ELECT 47uF 20% 50V
C841 1-127-811-11 ELECT 3300uF 20% 50V
(XGR60)
C841 1-127-753-11 ELECT 3300uF 20% 71V
(XGR6)
C842 1-127-814-11 ELECT 3300uF 20% 80V
(XGR60)
C844 1-137-749-11 MYLAR 0.1uF 100V
(XGR60)
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-21 CERAMIC 0.1uF 50V
C848 1-164-159-21 CERAMIC 0.1uF 50V
C849 1-164-159-21 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-286-21 CERAMIC 220PF 10% 50V
PAMOTORMIC/GUITAR
