68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
C854 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-21 CERAMIC 0.1uF 50V
C859 1-164-159-21 CERAMIC 0.1uF 50V
C861 1-130-491-00 MYLAR 0.047uF 5% 50V
C862 1-130-491-00 MYLAR 0.047uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
C891 1-127-811-11 ELECT 3300uF 20% 50V
(XGR60)
C891 1-127-753-11 ELECT 3300uF 20% 71V
(XGR6)
C892 1-127-814-11 ELECT 3300uF 20% 80V
(XGR60)
C894 1-137-749-11 MYLAR 0.1uF 100V
(XGR60)
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-21 CERAMIC 0.1uF 50V
C910 1-126-947-11 ELECT 47uF 20% 16V
(XGR6)
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN806 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-110-39 DIODE RD15ESB1 (XGR60)
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA204101 (XGR60)
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D835 8-719-200-82 DIODE 11ES2
D836 8-719-200-82 DIODE 11ES2
D841 8-719-200-82 DIODE 11ES2
D842 8-719-200-82 DIODE 11ES2
D843 8-719-200-82 DIODE 11ES2
D844 8-719-200-82 DIODE 11ES2
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-110-39 DIODE MTZJ-T-77-15A (XGR60)
D853 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
D911 8-719-982-24 DIODE MTZJ-33A
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 8-749-017-05 IC STK412-040 (XGR60)
IC801 8-749-017-16 IC STK442-130 (XGR6)
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA (XGR60)
Q401 8-729-140-82 TRANSISTOR 2SA988-PAFAEA (XGR6)
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q432 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-620-05 TRANSISTOR 2SC2603-EF
Q437 8-729-620-05 TRANSISTOR 2SC2603-EF
Q439 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q903 8-729-048-52 TRANSISTOR 2SA1932(TP)
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
0 R401 1-216-431-11 METAL OXIDE 560 5% 1W
(XGR60)
0 R401 1-216-458-11 METAL OXIDE 1.8K 5% 2W
(XGR6)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-249-433-11 CARBON 22K 5% 1/4W
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-249-433-11 CARBON 22K 5% 1/4W
(XGR60
R440 1-249-437-11 CARBON 47K 5% 1/4W
(XGR6)
R441 1-249-435-11 CARBON 33K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R460 1-249-429-11 CARBON 10K 5% 1/4W
(XGR6)
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-414-11 CARBON 560 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W
(XGR60)
R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W
(XGR60)
0 R807 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
PA
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
