Sony HCD-XGR60 - Panel VR, Sensor, Sub Trans, TC-A, TC-B, Trans Board Components

72
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
S711 1-762-875-21 SWITCH, KEYBOARD (GUITAR DISTORTION)
S713 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER)
S714 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER MODE)
S715 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
S716 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S717 1-762-875-21 SWITCH, KEYBOARD (TUNING -)
S718 1-762-875-21 SWITCH, KEYBOARD (TUNUNG +)
S719 1-762-875-21 SWITCH, KEYBOARD (FM MODE)
S720 1-762-875-21 SWITCH, KEYBOARD (TUNER ENTER)
S721 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY)
S722 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
******************************************************
*
1-659-058-13 SENSOR BOARD
************
< IC >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
******************************************************
1-683-445-11 SUB TRANS BOARD
**************
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN902 1-568-106-11 PIN, CONNECTOR 4P (XGR60:AR,E,E51)
* CN902 1-564-321-21 PIN, CONNECTOR 2P (XGR6,XGR60:MX)
< DIODE >
D901 8-719-983-61 DIODE MTZJ-T-72-3.3 (XGR60)
D901 8-719-991-33 DIODE 1SS133T-77 (XGR6)
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECT)
(XGR60:AR,E,E51)
< TRANSFORMER >
0 T901 1-437-331-11 TRANSFORMER, POWER (XGR60)
0 T901 1-435-826-11 TRANSFORMER, POWER (XGR6)
******************************************************
1-683-448-11 TC-A BOARD
*********
< DIODE >
D805 8-719-058-03 DIODE SEL5423E-TP15 (G )
D806 8-719-058-03 DIODE SEL5423E-TP15 (g )
< RESISTOR >
R813 1-247-843-11 CARBON 3.3K 5% 1/4W
R814 1-249-425-11 CARBON 4.7K 5% 1/4W F
R815 1-249-427-11 CARBON 6.8K 5% 1/4W F
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-431-11 CARBON 15K 5% 1/4W
R819 1-247-791-91 CARBON 22 5% 1/4W
R820 1-247-791-91 CARBON 22 5% 1/4W
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (GUITAR LEVEL)
RV802 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S810 1-762-875-21 SWITCH, KEYBOARD (G)
S811 1-762-875-21 SWITCH, KEYBOARD (g)
S812 1-762-875-21 SWITCH, KEYBOARD (x)
S813 1-762-875-21 SWITCH, KEYBOARD (.m)
S814 1-762-875-21 SWITCH, KEYBOARD (M>)
S815 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
******************************************************
1-683-449-11 TC-B BOARD
**********
< DIODE >
D801 8-719-058-03 DIODE SEL5423E-TP15 (G)
D802 8-719-058-03 DIODE SEL5423E-TP15 (g)
D803 8-719-057-97 DIODE SEL5923A-TP15 (X)
D804 8-719-058-04 DIODE SEL5223S-TP15 (zREC)
< RESISTOR >
R801 1-247-843-11 CARBON 3.3K 5% 1/4W
R802 1-249-425-11 CARBON 4.7K 5% 1/4W F
R803 1-249-427-11 CARBON 6.8K 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-431-11 CARBON 15K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R807 1-249-435-11 CARBON 33K 5% 1/4W
R808 1-249-439-11 CARBON 68K 5% 1/4W
R809 1-247-791-91 CARBON 22 5% 1/4W
R810 1-247-791-91 CARBON 22 5% 1/4W
R811 1-247-791-91 CARBON 22 5% 1/4W
R812 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (G)
S802 1-762-875-21 SWITCH, KEYBOARD (g)
S803 1-762-875-21 SWITCH, KEYBOARD (x)
S804 1-762-875-21 SWITCH, KEYBOARD (.m)
S805 1-762-875-21 SWITCH, KEYBOARD (M>)
S806 1-762-875-21 SWITCH, KEYBOARD (zREC)
S807 1-762-875-21 SWITCH, KEYBOARD (X)
S808 1-762-875-21 SWITCH, KEYBOARD (H SPEED DUB)
S809 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
******************************************************
1-683-444-11 TRANS BOARD
***********
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C834 1-137-749-11 MYLAR 0.1uF 100V
SUB TRANS TC-A TC-B TRANS
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SENSORPANEL VR
