Sony HCD-XGR60 - Trans Board Components

73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
C893 1-137-749-11 MYLAR 0.1uF 100V
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN951 1-564-214-11 PIN, CONNECTOR (B3PS-VH) 3P (XGR60)
* CN952 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D832 8-719-510-68 DIODE D5SBA204101
< FUSE HOLDER >
FH951 1-533-217-31 HOLDER, FUSE (XGR60:AR,E,E51)
FH952 1-533-217-31 HOLDER, FUSE (XGR60:AR,E,E51)
FH961 1-533-217-31 HOLDER, FUSE (XGR60)
FH962 1-533-217-31 HOLDER, FUSE (XGR60)
FH963 1-533-217-31 HOLDER, FUSE
FH964 1-533-217-31 HOLDER, FUSE
FH965 1-533-217-31 HOLDER, FUSE
FH966 1-533-217-31 HOLDER, FUSE
FH967 1-533-217-31 HOLDER, FUSE (XGR60)
FH968 1-533-217-31 HOLDER, FUSE (XGR60)
< RESISTOR >
0 R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W
0 R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W
0 R953 1-219-591-11 FUSIBLE 0.1 5% 1/2W
0 R961 1-219-777-91 CARBON 3.3M 10% 1/2W
(XGR6)
*******************************************************
TRANS
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
MISCELLANEOUS
*************
0 1-569-008-21 ADAPTOR, CONVERSION (XGR60:E51)
4 1-693-572-11 TUNER (FM/AM) (XGR60:AR,MX)
4 1-693-573-11 TUNER (FM/AM) (XGR6)
4 1-693-574-11 TUNER (FM/AM) (XGR60:E,E51)
5 1-769-945-11 WIRE (FLAT TYPE) (11 CORE)
7 1-535-706-21 PLUG, JUMPER (XGR6,XGR60:MX)
60 1-796-333-11 DECK, MECHANICAL
61 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
113 1-773-118-11 WIRE (FLAT TYPE) (19 CORE)
115 1-773-178-11 WIRE (FLAT TYPE) (23 CORE)
151 1-823-750-11 WIRE (FLAT TYPE) (21 CORE)
0 156 1-575-653-11 CORD, POWER (XGR60:MX)
0 156 1-777-071-81 CORD, POWER (XGR60:E51)
0 156 1-783-820-11 CORD, POWER (XGR6)
0 156 1-783-941-12 CORD, POWER (XGR60:AR)
0 156 1-791-901-11 CORD, POWER (XGR60:E)
556 A-4735-188-A BU-30 (60) ASSY
0 F951 1-532-506-31 FUSE (6.3A 250V) (XGR60:AR,E.E51)
0 F961 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (8.0A 250V)
(XGR60)
0 F962 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (8.0A 250V)
(XGR60)
0 F963 1-532-506-31 FUSE (6.3A 250V) (XGR60)
0 F963 1-533-310-11 FUSE, GLASS CYLINDRICAL(DIA.5)
(6.3A 125V)(XGR6)
0 F964 1-532-506-31 FUSE (6.3A 250V) (XGR60)
0 F964 1-533-310-11 FUSE, GLASS CYLINDRICAL(DIA.5)
(6.3A 125V)(XGR6)
M201 A-4660-977-A MOTOR ASSY
M901 1-763-072-11 FAN, DC
0 T951 1-433-606-11 TRANSFORMER, POWER (XGR60)
0 T951 1-435-797-11 TRANSFORMER, POWER (XGR6)
