70
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR88
MOTOR
R756 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R757 1-216-857-11 METAL CHIP 1M 5% 1/10W
R801 1-216-033-00 METAL CHIP 220 5% 1/10W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R803 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R804 1-216-841-11 METAL CHIP 47K 5% 1/10W
R805 1-216-841-11 METAL CHIP 47K 5% 1/10W
R806 1-216-833-11 METAL CHIP 10K 5% 1/10W
R807 1-216-821-11 METAL CHIP 1K 5% 1/10W
R808 1-216-845-11 METAL CHIP 100K 5% 1/10W
R810 1-216-845-11 METAL CHIP 100K 5% 1/10W
R812 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R813 1-216-833-11 METAL CHIP 10K 5% 1/10W
R814 1-216-837-11 METAL CHIP 22K 5% 1/10W
R815 1-216-837-11 METAL CHIP 22K 5% 1/10W
R816 1-216-845-11 METAL CHIP 100K 5% 1/10W
R911 1-215-863-11 METAL OXIDE 100 5% 1W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R921 1-216-833-11 METAL CHIP 10K 5% 1/10W
R922 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R923 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R924 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R961 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R962 1-216-836-11 METAL CHIP 18K 5% 1/10W
R963 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< TRANSFORMER >
T331 1-437-220-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X401 1-781-107-21 VIBRATOR, SERAMIC (8.19MHz)
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
******************************************************
A-4732-033-A MIC BOARD, COMPLETE
******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C802 1-162-215-31 CERAMIC 47PF 5% 50V
C803 1-126-960-11 ELECT 1uF 20% 50V
C804 1-126-959-11 ELECT 0.47uF 20% 50V
C805 1-162-294-31 CERAMIC 0.001uF 10% 50V
C806 1-162-215-31 CERAMIC 47PF 5% 50V
C810 1-162-286-31 CERAMIC 220PF 10% 50V
C817 1-126-961-11 ELECT 2.2uF 20% 50V
C818 1-162-215-31 CERAMIC 47PF 5% 50V
C819 1-162-215-31 CERAMIC 47PF 5% 50V
C821 1-126-947-11 ELECT 47uF 20% 16V
C822 1-126-767-11 ELECT 1000uF 20% 16V
C824 1-126-961-11 ELECT 2.2uF 20% 50V
C837 1-126-964-11 ELECT 10uF 20% 50V
C838 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN812 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< FILTER >
FL801 1-424-228-11 FILTER, NOISE
< IC >
IC850 8-759-505-55 IC NJM4558L
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE) (MIC-2)
J802 1-770-226-11 JACK (LARGE TYPE) (MIC-1)
< TRANSISTOR >
Q884 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R806 1-249-429-11 CARBON 10K 5% 1/4W
R807 1-249-429-11 CARBON 10K 5% 1/4W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R811 1-249-441-11 CARBON 100K 5% 1/4W
R850 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-899-11 CARBON 680K 5% 1/4W
R857 1-249-425-11 CARBON 4.7K 5% 1/4W F
R874 1-249-431-11 CARBON 15K 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W F
R877 1-249-411-11 CARBON 330 5% 1/4W
R878 1-249-417-11 CARBON 1K 5% 1/4W F
R879 1-249-417-11 CARBON 1K 5% 1/4W F
******************************************************
* A-4673-765-A MOTOR BOARD, COMPLETE
********************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP)
******************************************************
MAIN MIC
To Next Page
