71
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR88
PA
A-4732-056-A PA BOARD, COMPLETE
*****************
4-875-327-31 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C412 1-162-306-11 CERAMIC 0.01uF 30% 16V
C413 1-162-306-11 CERAMIC 0.01uF 30% 16V
C415 1-162-306-11 CERAMIC 0.01uF 30% 16V
C416 1-162-306-11 CERAMIC 0.01uF 30% 16V
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-162-290-31 CERAMIC 470PF 10% 50V
C803 1-162-286-31 CERAMIC 220PF 10% 50V
C804 1-126-965-91 ELECT 22uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C808 1-137-749-11 MYLAR 0.1uF 100V
C809 1-137-749-11 MYLAR 0.1uF 100V
C810 1-128-562-11 ELECT 47uF 20% 100V
C811 1-130-491-00 MYLAR 0.047uF 5% 50V
C812 1-130-491-00 MYLAR 0.047uF 5% 50V
C813 1-162-306-11 CERAMIC 0.01uF 30% 16V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-126-959-11 ELECT 0.47uF 20% 50V
C816 1-130-491-00 MYLAR 0.047uF 5% 50V
C817 1-130-467-00 MYLAR 470PF 5% 50V
C818 1-130-491-00 MYLAR 0.047uF 5% 50V
C819 1-130-467-00 MYLAR 470PF 5% 50V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-11 ELECT 47uF 20% 50V
C833 1-126-964-11 ELECT 10uF 20% 50V
C841 1-127-811-11 ELECT 3300uF 20% 50V
C842 1-127-815-11 ELECT 3300uF 20% 100V
C844 1-137-749-11 MYLAR 0.1uF 100V
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-11 CERAMIC 0.1uF 50V
C848 1-164-159-11 CERAMIC 0.1uF 50V
C849 1-164-159-11 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-286-31 CERAMIC 220PF 10% 50V
C854 1-126-965-91 ELECT 22uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-11 CERAMIC 0.1uF 50V
C859 1-164-159-11 CERAMIC 0.1uF 50V
C861 1-130-491-00 MYLAR 0.047uF 5% 50V
C862 1-130-491-00 MYLAR 0.047uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
C864 1-104-665-11 ELECT 100uF 20% 25V
C891 1-127-811-11 ELECT 3300uF 20% 50V
C892 1-127-815-11 ELECT 3300uF 20% 100V
C894 1-137-749-11 MYLAR 0.1uF 100V
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-11 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
* CN806 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-991-33 DIODE 1SS133T-77
D409 8-719-991-33 DIODE 1SS133T-77
D410 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-947-60 DIODE MTZJ-T-72-15A
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-066-42 DIODE RBV1306
D833 6-500-522-11 DIODE 10EDB40-TA2B5
D834 6-500-522-11 DIODE 10EDB40-TA2B5
D835 6-500-522-11 DIODE 10EDB40-TA2B5
D836 6-500-522-11 DIODE 10EDB40-TA2B5
D841 6-500-522-11 DIODE 10EDB40-TA2B5
D842 6-500-522-11 DIODE 10EDB40-TA2B5
D843 6-500-522-11 DIODE 10EDB40-TA2B5
D844 6-500-522-11 DIODE 10EDB40-TA2B5
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-947-60 DIODE MTZJ-T-72-15A
D853 8-719-991-33 DIODE 1SS133T-77
D902 6-500-522-11 DIODE 10EDB40-TA2B5
D903 6-500-522-11 DIODE 10EDB40-TA2B5
D904 6-500-522-11 DIODE 10EDB40-TA2B5
D905 6-500-522-11 DIODE 10EDB40-TA2B5
D911 8-719-983-86 DIODE MTZJ-T-72-33A
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 6-600-169-01 IC STK412-240
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q842 8-729-620-05 TRANSISTOR 2SC2603-EF
Q843 8-729-029-86 TRANSISTOR DTC124ESA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
To Next Page
