Sony HCD-XGR88 - Page 73

73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR88
PANEL FL
C617 1-164-159-11 CERAMIC 0.1uF 50V
C618 1-164-159-11 CERAMIC 0.1uF 50V
C619 1-124-233-91 ELECT 10uF 20% 16V
C620 1-162-300-11 CERAMIC 0.01uF 30% 16V
C622 1-126-960-11 ELECT 1uF 20% 50V
C623 1-126-960-11 ELECT 1uF 20% 50V
C624 1-126-947-11 ELECT 47uF 20% 16V
C625 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN601 1-784-741-11 CONNECTOR, FFC 19P
CN602 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-058-04 DIODE SEL5223S-TP15 (=/1)
< FLUORESCENT INDICATOR TUBE >
FL601 1-518-794-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 6-802-683-01 IC MB90M407APF-G-125-BND
IC602 8-759-826-34 IC NJL74H400A (SIRCS)
IC603 8-759-570-21 IC BA3830F
< COIL >
L603 1-410-332-31 INDUCTOR 47uH
< TRANSISTOR >
Q601 8-729-029-86 TRANSISTOR DTC124ESA
Q602 8-729-620-05 TRANSISTOR 2SC2603-EF
Q603 8-729-140-04 TRANSISTOR 2SB1116A-L
Q604 8-729-620-05 TRANSISTOR 2SC2603-EF
Q605 8-729-140-04 TRANSISTOR 2SB1116A-L
Q606 8-729-047-58 TRANSISTOR DTC114TLTL2
Q607 8-729-047-58 TRANSISTOR DTC114TLTL2
Q608 8-729-047-58 TRANSISTOR DTC114TLTL2
Q609 8-729-047-58 TRANSISTOR DTC114TLTL2
< RESISTOR >
R600 1-249-413-11 CARBON 470 5% 1/4W F
R601 1-249-441-11 CARBON 100K 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-247-807-31 CARBON 100 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-249-413-11 CARBON 470 5% 1/4W F
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-807-31 CARBON 100 5% 1/4W
R611 1-247-807-31 CARBON 100 5% 1/4W
R612 1-249-431-11 CARBON 15K 5% 1/4W
R613 1-249-431-11 CARBON 15K 5% 1/4W
R614 1-249-431-11 CARBON 15K 5% 1/4W
R615 1-249-431-11 CARBON 15K 5% 1/4W
R616 1-249-431-11 CARBON 15K 5% 1/4W
R617 1-249-431-11 CARBON 15K 5% 1/4W
R618 1-247-807-31 CARBON 100 5% 1/4W
R619 1-249-433-11 CARBON 22K 5% 1/4W
R620 1-247-903-00 CARBON 1M 5% 1/4W
R621 1-249-413-11 CARBON 470 5% 1/4W F
R622 1-249-415-11 CARBON 680 5% 1/4W F
R623 1-249-413-11 CARBON 470 5% 1/4W F
R624 1-247-891-91 CARBON 330K 5% 1/4W
R625 1-247-891-91 CARBON 330K 5% 1/4W
R626 1-249-437-11 CARBON 47K 5% 1/4W
R627 1-249-433-11 CARBON 22K 5% 1/4W F
R628 1-249-435-11 CARBON 33K 5% 1/4W
R629 1-249-413-11 CARBON 470 5% 1/4W F
R630 1-249-415-11 CARBON 680 5% 1/4W F
R631 1-249-417-11 CARBON 1K 5% 1/4W F
R632 1-249-419-11 CARBON 1.5K 5% 1/4W F
R633 1-249-419-11 CARBON 1.5K 5% 1/4W F
R634 1-249-411-11 CARBON 330 5% 1/4W
R635 1-247-871-91 CARBON 47K 5% 1/4W
R637 1-249-409-11 CARBON 220 5% 1/4W
R638 1-249-415-11 CARBON 680 5% 1/4W
R639 1-249-429-11 CARBON 10K 5% 1/4W
R640 1-247-877-91 CARBON 82K 5% 1/4W
R643 1-249-401-11 CARBON 47 5% 1/4W F
R647 1-249-413-11 CARBON 470 5% 1/4W F
R665 1-249-441-11 CARBON 100K 5% 1/4W
R666 1-249-441-11 CARBON 100K 5% 1/4W
R667 1-249-441-11 CARBON 100K 5% 1/4W
R668 1-249-441-11 CARBON 100K 5% 1/4W
R681 1-249-437-11 CARBON 47K 5% 1/4W
R683 1-249-437-11 CARBON 47K 5% 1/4W
R684 1-249-417-11 CARBON 1K 5% 1/4W F
R685 1-249-417-11 CARBON 1K 5% 1/4W F
R686 1-249-437-11 CARBON 47K 5% 1/4W
R688 1-249-437-11 CARBON 47K 5% 1/4W
R689 1-249-417-11 CARBON 1K 5% 1/4W F
R690 1-249-417-11 CARBON 1K 5% 1/4W F
R691 1-249-413-11 CARBON 470 5% 1/4W F
R692 1-249-413-11 CARBON 470 5% 1/4W F
R695 1-247-807-31 CARBON 100 5% 1/4W
R696 1-247-807-31 CARBON 100 5% 1/4W
R697 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S612 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION)
S613 1-762-875-21 SWITCH, KEYBOARD (c CLOCK SET)
S614 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S615 1-762-875-21 SWITCH, KEYBOARD (SLEEP)
S616 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S617 1-762-875-21 SWITCH, KEYBOARD (=/1)
S618 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< VIBRATOR >
X601 1-795-737-21 VIBRATOR, CERAMIC (4MHz)
******************************************************
A-4732-035-A PANEL VR BOARD, COMPLETE
(including MIC VR BOARD)
**********************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-162-294-31 CERAMIC 0.001uF 10% 50V
C704 1-126-947-11 ELECT 47uF 20% 16V
PANEL VR
