74
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR88
SENSORPANEL VR
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-164-159-11 CERAMIC 0.1uF 50V
C707 1-162-306-11 CERAMIC 0.01uF 30% 16V
C708 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN701 1-784-741-11 CONNECTOR, FFC 19P
CN702 1-563-616-11 CONNECTOR, FLEXIBLE 13P
< DIODE >
D701 8-719-058-64 DIODE SEL5823A-TP15 (VU 1)
D702 8-719-058-64 DIODE SEL5823A-TP15 (VU 2)
D703 8-719-058-64 DIODE SEL5823A-TP15 (VU 3)
D704 8-719-058-04 DIODE SEL5223S-TP15 (VU 4)
D705 8-719-058-04 DIODE SEL5223S-TP15 (VU 5)
D706 8-719-058-04 DIODE SEL5223S-TP15 (VU 6)
D707 8-719-058-04 DIODE SEL5223S-TP15 (VU 7)
D708 8-719-058-04 DIODE SEL5223S-TP15 (VU 8)
D709 8-719-058-04 DIODE SEL5223S-TP15 (VU 9)
D710 8-719-058-04 DIODE SEL5223S-TP15 (VU 10)
D711 8-719-058-04 DIODE SEL5223S-TP15 (VU 11)
D712 8-719-058-64 DIODE SEL5823A-TP15 (VU 12)
D713 8-719-058-64 DIODE SEL5823A-TP15 (VU 13)
D714 8-719-058-64 DIODE SEL5823A-TP15 (VU 14)
< IC >
IC701 8-759-373-50 IC NJU3719L
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-415-11 CARBON 680 5% 1/4W F
R708 1-249-402-11 CARBON 56 5% 1/4W F
R709 1-249-402-11 CARBON 56 5% 1/4W F
R710 1-249-402-11 CARBON 56 5% 1/4W F
R711 1-249-403-11 CARBON 68 5% 1/4W F
R712 1-249-403-11 CARBON 68 5% 1/4W F
R713 1-249-403-11 CARBON 68 5% 1/4W F
R714 1-249-403-11 CARBON 68 5% 1/4W F
R715 1-249-403-11 CARBON 68 5% 1/4W F
R716 1-249-403-11 CARBON 68 5% 1/4W F
R717 1-249-403-11 CARBON 68 5% 1/4W F
R718 1-249-403-11 CARBON 68 5% 1/4W F
R719 1-249-402-11 CARBON 56 5% 1/4W F
R720 1-249-402-11 CARBON 56 5% 1/4W F
R721 1-249-402-11 CARBON 56 5% 1/4W F
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S700 1-473-392-11 ENCODER, ROTARY (VOLUME)
S701 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
******************************************************
* 1-659-058-13 SENSOR BOARD
************
< IC >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
******************************************************
A-4732-054-A SUB AMP BOARD, COMPLETE
**********************
< CAPASITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-162-286-31 CERAMIC 220PF 10% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-126-965-91 ELECT 22uF 20% 50V
C105 1-136-165-00 MYLAR 0.1uF 5% 50V
C106 1-136-165-00 MYLAR 0.1uF 5% 50V
C107 1-128-560-11 ELECT 22uF 20% 100V
C108 1-136-495-11 FILM 0.068uF 5% 50V
C109 1-136-495-11 FILM 0.068uF 5% 50V
C113 1-162-306-11 CERAMIC 0.01uF 30% 16V
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C154 1-126-965-91 ELECT 22uF 20% 50V
C157 1-128-560-11 ELECT 22uF 20% 100V
C158 1-136-495-11 FILM 0.068uF 5% 50V
C159 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
* CN101 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-947-60 DIODE MTZJ-T-72-15A
D103 8-719-947-60 DIODE MTZJ-T-72-15A
D151 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 6-600-169-01 IC STK412-240
< TRANSISTOR >
Q101 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q151 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-441-11 CARBON 100K 5% 1/4W
R103 1-249-415-11 CARBON 680 5% 1/4W F
R105 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R106 1-216-436-00 METAL OXIDE 3.9K 5% 1W
0 R107 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R108 1-220-893-11 METAL 0.22 10% 5W
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SUB AMP
To Next Page
