75
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR88
SUB TRANS TC-A
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SUB AMP
R109 1-260-076-11 CARBON 10 5% 1/2W
R110 1-249-441-11 CARBON 100K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W F
R112 1-249-431-11 CARBON 15K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
0 R120 1-217-637-00 FUSIBLE 1 5% 1/4W
0 R128 1-220-893-11 METAL 0.22 10% 5W
R130 1-249-435-11 CARBON 33K 5% 1/4W
0 R138 1-220-893-11 METAL 0.22 10% 5W
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-441-11 CARBON 100K 5% 1/4W
R153 1-249-415-11 CARBON 680 5% 1/4W F
0 R157 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R158 1-220-893-11 METAL 0.22 10% 5W
R159 1-260-076-11 CARBON 10 5% 1/2W
R160 1-249-441-11 CARBON 100K 5% 1/4W
R161 1-249-417-11 CARBON 1K 5% 1/4W F
R162 1-249-431-11 CARBON 15K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
******************************************************
1-687-271-11 SUB TRANS BOARD
***************
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
CN902 1-568-106-11 PIN, CONNECTOR(3.96MM PITCH)4P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
0 RY901 1-755-467-11 RELAY (POWER)
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SERECTOR)
< TRANSFORMER >
0 T901 1-437-674-11 TRANSFORMER, POWER
******************************************************
1-687-256-11 TC-A BOARD
*********
< DIODE >
D502 8-719-058-03 DIODE SEL5423E-TP15 (g)
D503 8-719-058-03 DIODE SEL5423E-TP15 (G)
< RESISTOR >
R503 1-247-807-31 CARBON 100 5% 1/4W
R504 1-249-397-11 CARBON 22 5% 1/4W F
R505 1-249-415-11 CARBON 680 5% 1/4W F
R506 1-249-417-11 CARBON 1K 5% 1/4W F
R507 1-249-419-11 CARBON 1.5K 5% 1/4W F
R508 1-249-419-11 CARBON 1.5K 5% 1/4W F
R509 1-249-419-11 CARBON 1.5K 5% 1/4W F
R510 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S503 1-762-875-21 SWITCH, KEYBOARD (g)
S504 1-762-875-21 SWITCH, KEYBOARD (G)
S505 1-762-875-21 SWITCH, KEYBOARD (x)
S506 1-762-875-21 SWITCH, KEYBOARD (.m)
S507 1-762-875-21 SWITCH, KEYBOARD (M>)
S508 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
******************************************************
1-687-270-11 TRANS BOARD
***********
1-533-217-31 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACIOTR >
C834 1-137-749-11 MYLAR 0.1uF 100V
C893 1-137-749-11 MYLAR 0.1uF 100V
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN951 1-564-214-11 PIN, CONNECTOR(3.96MM PITCH)3P
* CN952 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D832 8-719-066-42 DIODE RBV1306
< RESISTOR >
0 R951 1-219-122-11 FUSEBLE 0.33 1/4W
0 R952 1-219-122-11 FUSEBLE 0.33 1/4W
0 R953 1-219-591-11 FUSEBLE 0.1 1/2W
******************************************************
A-4732-036-A TUNER/TC-B BOARD, COMPLETE
************************
< DIODE >
D901 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D903 8-719-058-03 DIODE SEL5423E-TP15 (g)
D904 8-719-058-03 DIODE SEL5423E-TP15 (G)
D905 8-719-057-97 DIODE SEL5923A-TP15 (X)
D906 8-719-058-04 DIODE SEL5223S-TP15 (z REC)
< RESISTOR >
R901 1-249-403-11 CARBON 68 5% 1/4W F
R903 1-249-421-11 CARBON 2.2K 5% 1/4W F
R904 1-247-843-11 CARBON 3.3K 5% 1/4W
R905 1-249-425-11 CARBON 4.7K 5% 1/4W F
R906 1-249-427-11 CARBON 6.8K 5% 1/4W F
R907 1-249-429-11 CARBON 10K 5% 1/4W
R908 1-249-431-11 CARBON 15K 5% 1/4W
R909 1-249-433-11 CARBON 22K 5% 1/4W
R910 1-249-435-11 CARBON 33K 5% 1/4W
R911 1-249-403-11 CARBON 68 5% 1/4W F
R912 1-249-403-11 CARBON 68 5% 1/4W F
R913 1-247-807-31 CARBON 100 5% 1/4W
R914 1-249-397-11 CARBON 22 5% 1/4W F
R915 1-249-415-11 CARBON 680 5% 1/4W F
R916 1-249-417-11 CARBON 1K 5% 1/4W F
R917 1-249-419-11 CARBON 1.5K 5% 1/4W F
TRANS
TUNER/TC-B
