Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR80
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
R918 1-249-419-11 CARBON 1.5K 5% 1/4W F
R919 1-249-421-11 CARBON 2.2K 5% 1/4W F
R920 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S901 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S902 1-762-875-21 SWITCH, KEYBOARD (TUNING -)
S903 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S904 1-762-875-21 SWITCH, KEYBOARD (MEMORY)
S905 1-762-875-21 SWITCH, KEYBOARD (FM MODE)
S906 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S907 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
S908 1-762-875-21 SWITCH, KEYBOARD (G)
S909 1-762-875-21 SWITCH, KEYBOARD (g)
S910 1-762-875-21 SWITCH, KEYBOARD (X)
S911 1-762-875-21 SWITCH, KEYBOARD (x)
S912 1-762-875-21 SWITCH, KEYBOARD (M>)
S913 1-762-875-21 SWITCH, KEYBOARD (.mz)
S914 1-762-875-21 SWITCH, KEYBOARD (z REC)
S915 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
******************************************************
MISCELLANEOUS
*************
0 1-569-008-22 ADAPTOR, CONVERSION 2P (E51)
4 1-693-603-41 TUNER (FM/AM)
5 1-769-945-11 WIRE (FLAT TYPE) (11 CORE)
67 1-773-108-11 WIRE (FLAT TYPE) (19 CORE)
111 1-773-114-11 WIRE (FLAT TYPE) (19 CORE)
112 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
126 1-769-986-11 WIRE (FLAT TYPE) (13 CORE)
127 1-796-487-31 DECK, MECHANICAL
151 1-823-750-11 WIRE (FLAT TYPE) (21 CORE)
0 156 1-823-767-12 CORD, POWER (E51)
0 156 1-823-824-12 CORD, POWER (E2)
555 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
556 A-4735-188-A BU-30 (60) ASSY
0 F951 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0 F961 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0 F962 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0 F963 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
0 F964 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8.0AL 250V)
M201 A-4660-977-A MOTOR ASSY
M901 1-763-072-11 FAN, DC
0 T951 1-439-703-11 TRANSFORMER, POWER
******************************************************
ACCESSORIES
***********
1-477-078-11 COMMADER, STANDARD (RM-SR6)
1-501-374-12 ANTENNA, LOOP
1-793-184-22 CONNECTOR (F TYPE ADAPTOR)
4-228-953-01 COVER, BATTERY (for RM-SR6)
4-245-987-11 OPERATING INSTRUCTIONS (ENGLISH)
4-245-987-21 OPERATING INSTRUCTIONS (FRENCH)(E2)
4-245-987-31 OPERATING INSTRUCTIONS (SPANISH)
TUNER/TC-B
