65
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR99AV
BD CD-L CD-R DOOR SW
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R102 1-216-845-11 METAL CHIP 100K 5% 1/10W
R103 1-216-835-11 METAL CHIP 15K 5% 1/10W
R104 1-216-839-11 METAL CHIP 33K 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R109 1-216-857-11 METAL CHIP 1M 5% 1/10W
R111 1-216-846-11 METAL CHIP 120K 5% 1/10W
R114 1-218-745-11 METAL CHIP 160K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R120 1-216-835-11 METAL CHIP 15K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-845-11 METAL CHIP 100K 5% 1/10W
R131 1-216-813-11 METAL CHIP 220 5% 1/10W
R143 1-216-839-11 METAL CHIP 33K 5% 1/10W
R144 1-216-839-11 METAL CHIP 33K 5% 1/10W
R147 1-218-701-11 METAL CHIP 2.4K 5% 1/10W
R148 1-216-797-11 METAL CHIP 10 5% 1/10W
R149 1-216-797-11 METAL CHIP 10 5% 1/10W
R158 1-216-838-11 METAL CHIP 27K 5% 1/10W
R159 1-216-838-11 METAL CHIP 27K 5% 1/10W
R162 1-216-845-11 METAL CHIP 100K 5% 1/10W
R171 1-216-837-11 METAL CHIP 22K 5% 1/10W
R172 1-216-837-11 METAL CHIP 22K 5% 1/10W
R173 1-216-837-11 METAL CHIP 22K 5% 1/10W
R181 1-216-837-11 METAL CHIP 22K 5% 1/10W
R182 1-216-837-11 METAL CHIP 22K 5% 1/10W
R183 1-216-837-11 METAL CHIP 22K 5% 1/10W
R190 1-216-813-11 METAL CHIP 220 5% 1/10W
R191 1-216-839-11 METAL CHIP 33K 5% 1/10W
R192 1-216-839-11 METAL CHIP 33K 5% 1/10W
R193 1-216-846-11 METAL CHIP 120K 5% 1/10W
R194 1-216-839-11 METAL CHIP 33K 5% 1/10W
R195 1-216-849-11 METAL CHIP 220K 5% 1/10W
R196 1-216-819-11 METAL CHIP 680 5% 1/10W
R198 1-216-864-11 METAL CHIP 0 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-238-602-11 RES, ADJ, CARBON 47K (E-F BALANCE)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (19.9344MHz)
******************************************************
1-687-265-11 CD-L BOARD
**********
< CONNECTOR >
* CN700 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R700 1-249-421-11 CARBON 2.2K 5% 1/4W F
R701 1-247-843-11 CARBON 3.3K 5% 1/4W
R702 1-249-425-11 CARBON 4.7K 5% 1/4W F
R703 1-249-427-11 CARBON 6.8K 5% 1/4W F
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-431-11 CARBON 15K 5% 1/4W
R706 1-249-433-11 CARBON 22K 5% 1/4W
R707 1-249-435-11 CARBON 33K 5% 1/4W
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S702 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S703 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S704 1-762-875-21 SWITCH, KEYBOARD (DISC1)
S705 1-762-875-21 SWITCH, KEYBOARD (DISC2)
S706 1-762-875-21 SWITCH, KEYBOARD (DISC3)
S707 1-762-875-21 SWITCH, KEYBOARD (DISC4)
S708 1-762-875-21 SWITCH, KEYBOARD (DISC5)
S709 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
******************************************************
1-687-266-11 CD-R BOARD
**********
< CONNECTOR >
CN600 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE)6P
< DIODE >
D600 8-719-056-13 DIODE SML79423C-TP15 (u)
< RESISTOR >
R600 1-249-425-11 CARBON 4.7K 5% 1/4W F
R601 1-249-427-11 CARBON 6.8K 5% 1/4W F
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-431-11 CARBON 15K 5% 1/4W
R604 1-249-433-11 CARBON 22K 5% 1/4W
R607 1-249-397-11 CARBON 22 5% 1/4W F
R608 1-249-397-11 CARBON 22 5% 1/4W F
< SWITCH >
S600 1-762-875-21 SWITCH, KEYBOARD (>)
S601 1-762-875-21 SWITCH, KEYBOARD (.)
S602 1-762-875-21 SWITCH, KEYBOARD (m)
S603 1-762-875-21 SWITCH, KEYBOARD (M)
S604 1-762-875-21 SWITCH, KEYBOARD (x)
S605 1-762-875-21 SWITCH, KEYBOARD (u)
******************************************************
1-687-267-11 DOOR SW BOARD
*************
< CAPACITOR >
C700 1-162-306-11 CERAMIC 0.01uF 30% 16V
< SWITCH >
S700 1-771-821-11 SWITCH, PUSH (1 KEY) (DOOR SW)
******************************************************
