77
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR99AV
R707 1-249-415-11 CARBON 680 5% 1/4W F
R708 1-249-402-11 CARBON 56 5% 1/4W F
R709 1-249-402-11 CARBON 56 5% 1/4W F
R710 1-249-402-11 CARBON 56 5% 1/4W F
R711 1-249-403-11 CARBON 68 5% 1/4W F
R712 1-249-403-11 CARBON 68 5% 1/4W F
R713 1-249-403-11 CARBON 68 5% 1/4W F
R714 1-249-403-11 CARBON 68 5% 1/4W F
R715 1-249-403-11 CARBON 68 5% 1/4W F
R716 1-249-403-11 CARBON 68 5% 1/4W F
R717 1-249-403-11 CARBON 68 5% 1/4W F
R718 1-249-403-11 CARBON 68 5% 1/4W F
R719 1-249-402-11 CARBON 56 5% 1/4W F
R720 1-249-402-11 CARBON 56 5% 1/4W F
R721 1-249-402-11 CARBON 56 5% 1/4W F
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S700 1-473-392-11 ENCODER, ROTARY (VOLUME)
S701 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
******************************************************
A-4732-081-A PROLOGIC BOARD, COMPLETE
**********************
< CAPACITOR >
C201 1-126-795-11 ELECT 10uF 20% 50V
C202 1-126-795-11 ELECT 10uF 20% 50V
C203 1-115-870-11 ELECT 0.47uF 20% 50V
C204 1-126-959-11 ELECT 0.47uF 20% 50V
C205 1-136-165-00 FILM 0.1uF 5% 50V
C206 1-136-165-00 FILM 0.1uF 5% 50V
C207 1-126-959-11 ELECT 0.47uF 20% 50V
C208 1-126-959-11 ELECT 0.47uF 20% 50V
C209 1-126-959-11 ELECT 0.47uF 20% 50V
C210 1-126-959-11 ELECT 0.47uF 20% 50V
C211 1-126-959-11 ELECT 0.47uF 20% 50V
C212 1-126-959-11 ELECT 0.47uF 20% 50V
C213 1-136-165-00 FILM 0.1uF 5% 50V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C215 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C216 1-126-960-11 ELECT 1uF 20% 50V
C217 1-130-479-00 MYLAR 0.0047uF 5% 50V
C218 1-130-471-00 MYLAR 0.001uF 5% 50V
C219 1-136-165-00 FILM 0.1uF 5% 50V
C220 1-136-169-00 FILM 0.22uF 5% 50V
C221 1-136-169-00 FILM 0.22uF 5% 50V
C222 1-136-165-00 FILM 0.1uF 5% 50V
C223 1-130-479-00 MYLAR 0.0047uF 5% 50V
C224 1-130-471-00 MYLAR 0.001uF 5% 50V
C225 1-115-871-11 ELECT 1uF 20% 50V
C226 1-130-480-00 MYLAR 0.0056uF 5% 50V
C227 1-136-161-00 FILM 0.047uF 5% 50V
C228 1-136-175-00 FILM 0.68uF 5% 50V
C229 1-136-169-00 FILM 0.22uF 5% 50V
C230 1-136-169-00 FILM 0.22uF 5% 50V
C231 1-126-963-11 ELECT 4.7uF 20% 50V
C232 1-126-963-11 ELECT 4.7uF 20% 50V
C233 1-136-169-00 FILM 0.22uF 5% 50V
C234 1-136-169-00 FILM 0.22uF 5% 50V
C235 1-136-165-00 FILM 0.1uF 5% 50V
C236 1-136-161-00 FILM 0.047uF 5% 50V
C237 1-136-161-00 FILM 0.047uF 5% 50V
C238 1-136-165-00 FILM 0.1uF 5% 50V
C239 1-136-165-00 FILM 0.1uF 5% 50V
C240 1-136-157-00 FILM 0.022uF 5% 50V
C241 1-136-157-00 FILM 0.022uF 5% 50V
C242 1-136-165-00 FILM 0.1uF 5% 50V
C243 1-130-469-00 MYLAR 680PF 5% 50V
C244 1-136-153-00 FILM 0.01uF 5% 50V
C245 1-136-153-00 FILM 0.01uF 5% 50V
C246 1-130-469-00 MYLAR 680PF 5% 50V
C247 1-136-153-00 FILM 0.01uF 5% 50V
C248 1-136-153-00 FILM 0.01uF 5% 50V
C249 1-126-947-11 ELECT 47uF 20% 16V
C250 1-130-481-00 MYLAR 0.0068uF 5% 50V
C251 1-126-963-11 ELECT 4.7uF 20% 50V
C252 1-126-934-11 ELECT 220uF 20% 16V
C253 1-126-934-11 ELECT 220uF 20% 16V
C255 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-126-964-11 ELECT 10uF 20% 50V
C258 1-126-964-11 ELECT 10uF 20% 50V
C259 1-126-964-11 ELECT 10uF 20% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-126-964-11 ELECT 10uF 20% 50V
C264 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C291 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C292 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN201 1-766-797-11 CONNECTOR, BOARD TO BOARD 10P
CN202 1-766-797-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
< FILTER >
FL201 1-233-289-21 FILTER, EMI (SMD)
< IC >
IC201 8-759-571-51 IC M62464FP
< COIL >
L201 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q271 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q291 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R201 1-216-809-11 METAL CHIP 100 5% 1/10W
R202 1-216-809-11 METAL CHIP 100 5% 1/10W
R203 1-216-817-11 METAL CHIP 470 5% 1/10W
R204 1-216-851-11 METAL CHIP 330K 5% 1/10W
R205 1-216-841-11 METAL CHIP 47K 5% 1/10W
PANEL VR
PROLOGIC
