46
Menu List
<SPIRIT LEVEL>
08
INDICATOR ON, OFF When this is set to ON, BOX MEMORY for
CURSOR does not function.
V POSITION 0 to 99, 97
ANGLE Sets the inclination angle. (Display only)
OFFSET –99 to +99, 0
SET
ZERO
ANGLE
Execute via ENTER. Designates the current angle as level (0°).
CLEAR Execute via ENTER. Sets OFFSET to 0.
<VF OUT>
09 (U01)
VF OUT COLOR
, Y, R, G, B, (COLOR), (Y),
(R), (G), (B), (RET), (R+G), (R+B),
(G+B)
Settings in ( ): When HDLA is attached (cannot be
changed)
RET MIX VF ON, OFF
, (ON), (OFF) Settings in ( ): When HDLA is attached (cannot be
changed)
MIX DIRECTION MAIN, RET
MIX VF MODE Y-MIX, WIRE(W), WIRE(B)
MIX VF LEVEL 0 to 80%
CHARACTER LEVEL 0 to 5, 5
PinP ON, OFF, (OFF) Cannot be used during stand-alone operation.
Not available when HD TRUNK FRAME SYNCHRO
is set to ON.
POSITION 1
, 2, 3, 4
SIZE 1/3
, 1/4
<SWITCH ASSIGN1>
10 (U09)
GAIN L: –6, –3, 0
, 3, 6, 9, 12 dB
M: –6, –3, 0, 3, 6
, 9, 12 dB
H: –6, –3, 0, 3, 6, 9, 12
dB
ASSIGNABLE OFF
, RETURN1 SW, RETURN2
SW, INCOM1, INCOM2, VF
DETAIL, MIX VF, 5600K, FAN
MAX, D.EXTENDER, VF ASSIGN
SW1, VF ASSIGN SW2, SPIRIT
LEVEL INDICATOR, FOCUS
ASSIST INDICATOR, PinP
JN/SY/UC models only.
When HDLA is attached: OFF, EXTENDER, 5600K,
FAN MAX, D.EXTENDER, PinP
Note
When you turn D.EXTENDER ON or OFF, noise
may be generated. This is not a malfunction.
D.EXTENDER does not operate when a 2x speed
motion format is selected.
OFF
, RETURN1 SW, RETURN2
SW, ENG, PROD, VF DETAIL,
MIX VF, 5600K, FAN MAX,
D.EXTENDER, VF ASSIGN SW1,
VF ASSIGN SW2, SPIRIT LEVEL
INDICATOR, FOCUS ASSIST
INDICATOR, PinP
CE/E models only.
When HDLA is attached: OFF, EXTENDER, 5600K,
FAN MAX, D.EXTENDER, PinP
Note
When you turn D.EXTENDER ON or OFF, noise
may be generated. This is not a malfunction.
D.EXTENDER does not operate when a 2x speed
motion format is selected.
OPERATION
Page title
PageNo.
Item Settings Description
