56
Menu List
<TEST OUT>
M10 (U13)
OUTPUT SD-SYNC, HD-SYNC, VF, VBS
VBS-OUT OUTPUT is displayed during VBS.
CHARACTER ON, OFF
GAIN –99 to +99, 0
CHROMA –99 to +99, 0
SETUP ON, OFF JN/SY/UC models only (displayed when the format
is NTSC)
SYNC-OUT OUTPUT is displayed during SD-SYNC and HD-
SYNC.
V-PHASE –999 to +999, 0
H-PHASE –999 to +999, 0
DOWN CONVERTER OUTPUT is displayed for VBS.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
<SDI OUT>
M11 (U14)
SDI-1 OUT OFF, MAIN/LINK-A
, 3G-SDI, HD
PROMPTER
HDC2500/2400 only
SDI-2 OUT/IN OFF, MAIN/LINK-B
, HD TRUNK/
RET IN
HDC2500/2400 only
FRAME
SYNCHRO
ON, OFF
Displays this when SDI-2 OUT/IN is HD TRUNK.
SDI-MONI OUT MAIN
, VF, LINK-B, RET, SD-SDI,
OFF
LINK-B is available for HDC2500 only.
CHARACTER ON, OFF
EMB AUDIO OFF, MIC, PGM
DOWN CONVERTER SDI-MONI OUT is displayed for SD-SDI.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
COAX MODE ON, OFF
HDC2500/2400 only (Not displayed with CCU
connected.)
Enables or disables COAX connection.
<TRUNK>
(HDC2500/2400)
M12
TRUNK ON
, OFF
INTERFACE 232c
, 422A
AUX REMOTE Display only
NETWORK TRUNK Display only
LINK
<GENLOCK>
M13
REFERENCE Condition of synchronisation Display only
GENLOCK ENABLE
, DISABLE Displayed only when no CCU connected.
STATUS
FORMAT
PHASE
V –1024 to +1023, 0
HD H –1700 to +1700, 0
SD H –1024 to +1023, 0
<DATE>
M14
DATE/TIME 2000 to 2099 / 01 to 12 / 00 to 31,
00 to 23 : 00 to 59
FILE TIMESTAMP
FORMAT
1 Y/Mn/D, 2 Mn/D, 3 D/M/Y, 4 D/M,
5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (character string)
D: Day
<BATTERY ALARM>
M15
BEFORE END 11.5
to 17.0 V
END 11.0
to 11.5 V
MAINTENANCE
Page title
PageNo.
Item Settings Description
