55
Menu List
<LENS>
M06
F NO. DISP CONTROL, RETURN Selects the iris indication on the panel when AUTO
IRIS is off:
CONTROL: Displays the value from the camera
RETURN: Displays the value returned from the lens.
(When AUTO IRIS is on, the value returned from the
lens is always displayed.)
ALAC AUTO
, OFF With AUTO selected, the status is displayed at the
right.
(ACTIVE): Compensation is in progress.
(WAIT): Waiting for completion of lens initialization.
(STOP): Compensation is turned off for a non-
applicable lens.
OPAC ON, OFF
Sets the optical axis compensation (OPAC) function
to ON/OFF.
H SHIFT –5, –4, –3, –2, –1, 0
, 1, 2, 3, 4, 5 Sets the H-direction movement amount.
V SHIFT –3, –2, –1, 0
, 1, 2, 3 Sets the V-direction movement amount.
MARKER ON
, OFF Sets VF MARKER to ON/OFF. (This has the same
function as MARKER on the VF MARKER page in
the OPERATION menu.)
CENTER ON, OFF
Sets the center marker to ON/OFF.
H POS –48 to +48, 0
Display only
(The value of H POS on the LENS FILE page in the
FILE menu is displayed.)
V POS –27 to +27, 0
Display only
(The value of V POS on the LENS FILE page in the
FILE menu is displayed.)
<MIC GAIN>
M07
MIC1 20, 30, 40, 50, 60
dB Valid only in standalone operation.
MIC2 20, 30, 40, 50, 60
dB
<CALL/TALLY>
M08
CCU CALL OFF, ON
, --- --- : With no CCU connected (cannot be changed)
CAM CALL OFF
, ON, ---
UP TALLY
BRIGHTNESS
TALLY 0 to 100, 50
NUMBER 0 to 100, 50
CAMERA NUMBER ---, 1 to 96
NUMBER DISPLAY ON, OFF, AUTO
AUTO: When HDLA is attached, corresponds to the
UP TALLY switch setting.
<OUTPUT FORMAT>
(HDC2500)
M09 (U12)
CURRENT 1080: 24PsF, 59.94i, 29.97PsF,
23.98PsF, 59.94P, 50i, 25PsF,
50P, 59.94i × 2, 50i × 2
720: 59.94P, 50P, 59.94P × 2,
50P × 2
Displays the current format.
<OUTPUT FORMAT>
(HDC2400/2550)
M09 (U12)
CURRENT 1080: 59.94i, 50i
720: 59.94P, 50P
Displays the current format.
MAINTENANCE
Page title
PageNo.
Item Settings Description
