<VF DISPLAY>
01 (U04)
FOCUS FORM NORMAL
, ABS (AUTO), ABS
(m), ABS (ft)
Sets the focus display method.
NORMAL: Displays a value in the range 0 to 255 (no
units).
ABS (AUTO): Displays in units of meters or feet,
according to the units setting on the lens.
ABS (m): Displays in meters.
ABS (ft): Displays in feet.
The NORMAL setting is not available when a Cooke
lens is attached. The default is ABS (AUTO).
<‘!’ IND>
02 (U05)
ND ON
, OFF
1
, 2, 3 (combination allowed)
[IND]: Turns the ‘!’ display area (page 23) on/off.
[NORMAL]: Specifies the conditions under which the ‘!’
indication is not to be displayed even if [IND] is ON.
(By specifying the standard or normal conditions
here, non-standard or abnormal conditions can be
found with the ‘!’ indication on the viewfinder
screen.)
e.g.: With the default setting of ND, the ‘!’ indicator is
displayed when an ND filter other than 1 is selected.
CC ON
, OFF
A
, B, C (combination allowed)
FAN ON
, OFF
AUTO1
, AUTO2, MIN, MAX
EXT ON
, OFF
Y TALLY ON
, OFF
<VF MARKER>
03 (U06)
MARKER ON
, OFF Sets MARKER to ON/OFF.
WHITE
, BLACK, DOT
LEVEL 0 to 100%, 40%
CENTER ON, OFF
1, 2, 3, 4 1: Full cross hairs
2: Full cross hairs with a hole
3: Center
4: Center with a hole
SAFETY ZONE ON, OFF
80.0, 90.0, 92.5, 95.0%
EFFECT ON, OFF
, OFF(ASSIST IND),
OFF(AF DISP)
OFF(ASSIST IND): Displayed when INDICATOR of
<FOCUS ASSIST> is ON.
OFF(AF DISP): Displayed when AF DISPLAY of
<LENS> is ON.
ASPECT ON, OFF
16:9, 15:9, 14:9, 13:9, 4:3, (4.3) (4.3): If VF SCAN is set to 4:3 when HDLA is attached
(cannot be changed)
MASK ON, OFF
, (ON) (ON): If VF SCAN is set to 4:3 when HDLA is attached
(cannot be changed)
0 to 15, 12
Sets the darken level outside the aspect area.
SAFETY ON, OFF
, (AREA) Sets the safety marker in Aspect mode.
OFF(AREA): Displayed when AREA MARKER of
<FOCUS ASSIST> is ON.
80.0, 90.0
, 92.5, 95.0%
OPERATION
Page name
Page No.
Item Settings Description
