Sony HDC4800 - Specifications

57
Specifications
HDC4800
Design and specifications are subject to change without
notice.
General
Power requirements 240 V AC, 1.4 A (max.)
180 V DC, 1.0 A (max.)
12 V DC, 9.5 A (max.)
Operating temperature –20 °C to +45 °C (–4 °F to +113 °F)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Mass Approx. 5.0 kg (11 lb 0.37 oz) (Unit only)
Dimensions See page 58.
Imaging element
Imaging element S-35 mm CMOS image sensor
Method Single chip
Effective resolution QFHD: 3840 (horizontal) × 2160
(vertical)
HD: 1920 (horizontal) × 1080 (vertical)
Electrical
characteristics
Sensitivity T5.6 (at 2000 lx with 89.9% reflectance.
For 4K/59.94P (8×))
Image S/N HD/59.94i: –62 dB
Horizontal resolution 2000 TVL (4K: screen centered)
5% or higher modulation
Geometric distortion Negligible (not including lens distortion)
Optical system
specifications
Built-in filters Color temperature conversion filters
A: 3200K (clear)
B: 4300K
C: 6300K
ND filters
1: Clear
2: 1/4 ND
3: 1/16 ND
Input/output
connectors
BPU Optical/electrical multi-connector (1)
LENS 12-pin (1)
VF 20-pin (1)
AUDIO IN CH1, CH2 XLR 3-pin, female (1 each)
When AUDIO switch is set to MIC:
–60 dBu (can be selected up to
–20 dBu by menu or HDCU2000/2500
operations), balanced
When AUDIO switch is set to LINE:
0 dBu, balanced
INTERCOM 1,
INTERCOM 2
XLR 5-pin, female (1 each)
EARPHONE Stereo minijack (1)
DC IN XLR 4-pin (1), 10.5 V to 17 V DC
DC OUT 4-pin (1), 10.5 V to 17 V DC, max. 0.5 A
(This may be limited by the imposed load
or inputs.)
2-pin (1), 10.5 V to 17 V DC, max. 2.5 A
(This may be limited by the imposed load
or inputs.)
SDI 1, SDI 2 BNC-type (1 each)
SDI-MONI BNC-type (1)
TEST OUT BNC-type (1)
PROMPTER BNC-type (1), 1 Vp-p, 75 ohm
PROMPTER2 BNC-type (1), 1 Vp-p, 75 ohm
RET CTRL 6-pin (1)
REMOTE 8-pin (1)
TRACKER 10-pin (1)
CRANE 12-pin (1)
USB USB 2.0 Type A 4-pin (1) (for connecting
USB drive)
NETWORK TRUNK RJ-45 type 8-pin (1)
Supplied accessories
Before Using this Unit (1 set)
Operating Instructions (CD-ROM) (1)
Lens mount adaptor (1)
Cable clamp belt (1 set)
Camera number label (1)
Screws (+B3×8) (2)
