48
MAINTENANCE Menu
<SCENE FILE>
P18
1 Saving and loading a scene file (paint data):
When storing a file in camera memory, specify the
number after executing STORE.
When reading, only specify the number.
2
3
4
5
STORE Execute using ENTER.
STANDARD Execute using ENTER. Reads the standard paint data.
READ (USB t CAM) Execute using ENTER. Loads five scene files from a USB drive to internal
memory.
WRITE (CAM t USB) Execute using ENTER. Writes five scene files in the camera’s memory to a
USB drive.
FILE ID Max. 16 characters Enters a comment for the scene files to be written to a
USB drive.
See “To specify a character string” (page 26).
CAM CODE Camera code Display only
DATE Date Display only
DISSOLVE OFF
, ON Switching a scene file seamlessly.
SPEED 0.2 to 2.8 (0.2 steps), 3 to 10 (1
steps), 0.2
MAINTENANCE
Page name
Page No.
Item Settings Description
<AUTO SETUP>
M01
AUTO BLACK Execute using ENTER.
AUTO WHITE Execute using ENTER.
AUTO LEVEL Execute using ENTER.
TEST OFF
, SAW, 10STEP
<WHITE SHADING>
M02
V SAW R/G/B: –99 to +99, 0
R, G, and B values can be independently set.
V PARA R/G/B: –99 to +99, 0
H SAW R/G/B: –99 to +99, 0
H PARA R/G/B: –99 to +99, 0
WHITE R/G/B: –99 to +99, 0
<BLACK SHADING>
M03
V SAW R/G/B: –99 to +99, 0 R, G, and B values can be independently set.
M (master) value can also be set for BLACK.
V PARA R/G/B: –99 to +99, 0
H SAW R/G/B: –99 to +99, 0
H PARA R/G/B: –99 to +99, 0
BLK SET R/G/B: –99 to +99, 0
BLACK R/G/B/M: –99 to +99, 0
MASTER GAIN –6, –3, 0, 3, 6, 9, 12 dB
<OHB MATRIX>
M04
OHB MATRIX ON, OFF
MATRIX ON, OFF
PAINT
Page name
Page No.
Item Settings Description
