49
<AUTO IRIS>
M05
AUTO IRIS ON, OFF
, (ON), (OFF) Settings in ( ): When a remote control unit/panel or a
CCU is not connected (cannot be changed)
WINDOW 1
, 2, 3, 4, 5, 6 Selects the auto iris windows:
The shaded parts indicate the area where light
detection occurs.
OVERRIDE –99 to 99, 0
, --- Sets to temporarily change the reference value for
brightness of the automatic iris level in the range of ±2
steps:
–99: Two steps to fully closed iris.
99: Two steps to fully opened iris.
---: OFF
The setting returns to “---” when the power is turned
off.
IRIS LEVEL –99 to +99, 0
±4 steps
APL RATIO –99 to +99, 65
IRIS GAIN –99 to +99, 0
IRIS CLOSE ON, OFF
<LENS>
M06
F NO. DISP CONTROL, RETURN Selects the iris indication on the panel when AUTO
IRIS is off:
CONTROL: Displays the value from the camera
RETURN: Displays the value returned from the lens.
(When AUTO IRIS is on, the value returned from the
lens is always displayed.)
ALAC AUTO
, OFF With AUTO selected, the status is displayed at the
right.
(ACTIVE): Compensation is in progress.
(WAIT): Waiting for completion of lens initialization.
(STOP): Compensation is turned off for a non-
applicable lens.
AF DISPLAY ON, OFF
, OFF(EFFECT),
OFF(ASSIST IND)
OFF(EFFECT): Displayed when EFFECT of <VF
MARKER> is ON.
OFF(ASSIST IND): Displayed when INDICATOR of
<FOCUS ASSIST> is ON.
<MIC GAIN>
M07
MIC1 20, 30, 40, 50, 60
dB
MIC2 20, 30, 40, 50, 60
dB
<CALL/TALLY>
M08
CCU CALL OFF, ON
, --- --- : With no CCU connected (cannot be changed)
CAM CALL OFF
, ON, ---
UP TALLY BRIGHTNESS Enabled when connected to an HDLA.
TALLY 0 to 100, 50
NUMBER 0 to 100, 50
NUMBER DISPLAY AUTO, OFF, ON
CAMERA NUMBER ---
, 1 to 96
CCU LINK OFF
, ON ON sets CAMERA NUMBER to the same number as
the CCU number.
TALLY GUARD Prevents changes when the red tally lamp is lit.
EXTENDER OFF
, ON
FILTER DISC OFF
, ON
MAINTENANCE
Page name
Page No.
Item Settings Description
123
456
To Next Page
