54
<BOARD STATUS>
D02
OHB OK, NG
DPR OK, NG
SY OK, NG
PS OK, NG
TX OK, NG
HOURS METER xxxx H Displays the total working time.
<ROM VERSION>
D03 (U15)
CAMERA APP Vx.xx
OS Vx.xx
PANEL Vx.xx Displayed only when HDLA is attached.
SY Vx.xx
DPR Vx.xx
TX Vx.xx
TX2 Vx.xx
PS Vx.xx
<SERIAL No.>
D04
MODEL HDC4800
NO. xxxxxxx
EFFECTIVE FUNCTION Displayed if any option is installed.
<POWER SUPPLY
STATUS>
D05
This display has a
margin of error for the
display of the electric
supply state of a
camera. Use only as a
guide.
CAM INPUT VOLTAGE 0% to 100%, 100% OVER Displays the ratio of the input voltage for a
camera to the output voltage for a CCU.
CAM CONSUMPTION xx.x A Displays camera current consumption.
CABLE LENGTH x.x km Displays the cable length that a CCU
measured. (Displayed only when a CCU is
connected.)
DIAGNOSIS
Page name
Page No.
Item Indication Description
Note
