8
GB
Name Function
J Tuner
indicators
Lights up when using the
receiver to tune in radio stations
(page 55), etc.
K Preset
station
indicators
Lights up when using the
receiver to tune in preset radio
stations. For details on
presetting radio stations, see
page 56.
L D.RANGE Lights up when dynamic range
compression is activated (page
40).
M NEO:6 Lights up when DTS Neo:6
Cinema/Music decoder is
activated (page 50).
N COAX Lights up when INPUT MODE
is set to “AUTO IN” and the
source signal is a digital signal
being input through the
COAXIAL jack, or when
INPUT MODE is set to “COAX
IN” (page 61).
O Playback
channel
indicators
L
R
C
SL
SR
S
SB
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
the letters vary to show how the
receiver downmixes the source
sound.
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Surround Back (the surround
back components obtained by
6.1 channel decoding)
Example:
Recording format (Front/
Surround): 3/2.1
Sound Field: A.F.D. AUTO
SW
LCR
SL SR
