5-19
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
HVR-Z5C/Z5E/Z5J/Z5N/Z5P/Z5U
A-1599-643-A AS-060 BOARD, COMPLETE
**********************
< CONNECTOR >
CN8801 1-817-920-11 CONNECTOR, FPC (ZIF) 80P
CN8802 1-817-920-11 CONNECTOR, FPC (ZIF) 80P
< RESISTOR >
R8804 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R8805 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
< SWITCH >
S8801 1-786-157-31 TACTILE SWITCH (4 (ASSIGN))
S8802 1-786-157-31 TACTILE SWITCH (5 (ASSIGN))
S8803 1-786-157-31 TACTILE SWITCH (6 (ASSIGN))
< VARISTOR >
* VDR881 1-802-279-11 VARISTOR (SMD)
************************************************************
A-1599-835-A CK-204 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN8001 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
CN8002 1-816-655-61 CONNECTOR, FFC/FPC 8P
* CN8003 1-779-333-51 CONNECTOR, FFC/FPC 18P
* CN8004 1-779-331-51 CONNECTOR, FFC/FPC 14P
* CN8005 1-779-327-51 CONNECTOR, FFC/FPC 6P
< RESISTOR >
R8001 1-218-970-11 METAL CHIP 27K 5% 1/16W
R8002 1-218-970-11 METAL CHIP 27K 5% 1/16W
R8003 1-218-970-11 METAL CHIP 27K 5% 1/16W
R8004 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R8005 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R8006 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R8007 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R8008 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R8009 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R8011 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8012 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8013 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8014 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8015 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R8016 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R8018 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R8019 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R8020 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R8022 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R8029 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R8030 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R8031 1-218-970-11 METAL CHIP 27K 5% 1/16W
************************************************************
A-1566-526-A DEVICE (SERVICE), PRISM (Note)
(Not supplied) CM-097 BOARD, COMPLETE
***********************
(CM-097 complete board and all mounted parts (including IC3001 (CMOS
IMAGER)) are not supplied, but they are included in PRISM DEVICE
(SERVICE).)
************************************************************
A-1566-526-A DEVICE (SERVICE), PRISM (Note)
(Not supplied) CM-104 BOARD, COMPLETE
***********************
(CM-104 complete board and all mounted parts (including IC5001 (CMOS
IMAGER)) are not supplied, but they are included in PRISM DEVICE
(SERVICE).)
************************************************************
(Not supplied) FP-031 FLEXIBLE BOARD
********************
(This flexible board is included in MD (N220) sub assy (S) A (A-1437-006-A).)
< DIODE >
D902 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T
(S REEL SENSOR)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T
(T REEL SENSOR)
< CONNECTOR >
MIC902 1-818-576-11 PIN, CONNECTOR (WITH DETECTION)
(4 PIN CONNECTOR)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F
(TAPE END SENSOR)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F
(TAPE TOP SENSOR)
< SWITCH >
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
************************************************************
(Not supplied) FP-032 FLEXIBLE BOARD
********************
(This flexible board with S903 is included in MD (N220) sub assy (S) A (A-
1437-006-A).)
************************************************************
Note: イメージャの交換時は4-4ページのイメージャ交換時
の注意を必ずお読みください。
Note: Be sure to read “Precuations for Replacement of Imager”
on page 4-3 when changing the imager.
FP-032FP-031CM-104
CM-097CK-204AS-060
