Sony HVR-Z5E User Manual

5-21
Ref. No. Part No. Description Ref. No. Part No. Description
HVR-Z5C/Z5E/Z5J/Z5N/Z5P/Z5U
R7806 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R7812 1-216-864-11 SHORT CHIP 0
< SWITCH >
S7801 1-771-487-11 SWITCH, SLIDE (HANDLE ZOOM)
************************************************************
A-1602-003-A GY-014 BOARD, COMPLETE (SERVICE)
**********************
< CAPACITOR >
C8501 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
C8502 1-112-746-11 CAP, CERAMIC 4.7uF 10% 6.3V
C8503 1-112-746-11 CAP, CERAMIC 4.7uF 10% 6.3V
C8504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8505 1-114-411-21 CAP, CERAMIC 0.33uF 10% 6.3V
C8506 1-114-411-21 CAP, CERAMIC 0.33uF 10% 6.3V
C8507 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
C8508 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
C8509 1-119-923-11 CAP, CERAMIC 0.047uF 10% 10V
C8510 1-119-923-11 CAP, CERAMIC 0.047uF 10% 10V
C8511 1-119-923-11 CAP, CERAMIC 0.047uF 10% 10V
C8512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8513 1-119-923-11 CAP, CERAMIC 0.047uF 10% 10V
C8514 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8515 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8519 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8520 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
C8521 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
C8522 1-165-989-11 CAP, CERAMIC 10uF 10% 6.3V
< CONNECTOR >
CN8501 1-816-655-61 CONNECTOR, FFC/FPC 8P
< IC >
* IC8501 8-753-284-38 IC CXA3739AER-T2
< RESISTOR >
R8509 1-218-989-11 RES, CHIP 1M 5% 1/16W
R8510 1-218-989-11 RES, CHIP 1M 5% 1/16W
R8511 1-208-911-11 RES, CHIP 10K 0.50% 1/16W
R8512 1-208-911-11 RES, CHIP 10K 0.50% 1/16W
R8513 1-208-711-11 RES, CHIP 15K 0.50% 1/16W
R8514 1-208-711-11 RES, CHIP 15K 0.50% 1/16W
R8515 1-218-969-11 RES, CHIP 22K 5% 1/16W
R8516 1-218-969-11 RES, CHIP 22K 5% 1/16W
R8517 1-218-969-11 RES, CHIP 22K 5% 1/16W
R8518 1-218-969-11 RES, CHIP 22K 5% 1/16W
R8529 1-218-990-81 SHORT CHIP 0
R8530 1-218-990-81 SHORT CHIP 0
< SENSOR >
* SE8501 1-480-218-11 SENSOR, ANGULAR VELOCITY (31.2kHz)
(PITCH SENSOR)
* SE8502 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2kHz)
(YAW SENSOR)
************************************************************
A-1599-843-A HP-153 BOARD, COMPLETE
***********************
< CAPACITOR >
C9202 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C9203 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C9204 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C9205 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN9201 1-779-328-51 CONNECTOR, FFC/FPC 8P
< DIODE >
D9201 6-501-257-01 DIODE CL-197TLY-CD-T
< FERRITE BEAD >
FB9202 1-400-927-31 BEAD, FERRITE (1005)
FB9203 1-400-927-31 BEAD, FERRITE (1005)
< JACK >
J9201 1-794-525-12 JACK, MIC (HEADPHONE)
< COIL >
L9201 1-400-922-11 INDUCTOR 220uH
L9202 1-400-922-11 INDUCTOR 220uH
************************************************************
A-1599-828-A HT-002 BOARD, COMPLETE
**********************
< CONNECTOR >
CN7401 1-794-375-21 PIN, CONNECTOR 2P
< SWITCH >
S7401 1-786-180-11 SWITCH, PUSH (1KEY) (PANEL REVERSE)
************************************************************
A-1599-841-A JK-376 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN9507 1-779-335-51 CONNECTOR, FFC/FPC 22P
CN9508 1-815-794-13 CONNECTOR (MULTIPLE) (A/V R)
* CN9509 1-794-276-21 CONNECTOR, SQUARE TYPE 4P (HDV/DV)
< FERRITE BEAD >
FB9501 1-400-927-31 BEAD, FERRITE (1005)
FB9502 1-400-927-31 BEAD, FERRITE (1005)
< COMPOSITION CIRCUIT BLOCK >
RB9501 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
JK-376HT-002
HP-153GY-014GP-025

Sony HVR-Z5E Specifications

General

Filter size	72 mm
Digital zoom	0 x
Optical zoom	20 x
Image stabilizer	No
Focal length range	36.1 - 590 mm
Interchangeable lens	Yes
Sensor type	CMOS
Total megapixels	- MP
Optical sensor size	1/3 \
Viewfinder type	-
Viewfinder resolution	1226880 pixels
Viewfinder screen size	0.45 \
Display diagonal	3.2 \
Display aspect ratio	16:9
Maximum video resolution	- pixels
Analog signal format system	PAL
Camcorder tape type	HDV
Camcorder media type	Videotape
Internal storage capacity	- GB
Camera shutter speed	1/4 - 1/10000 s
Camcorder type	Shoulder camcorder
Minimum illumination	1.5 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	188 mm
Width	169 mm
Height	451 mm
Weight	2200 g
