16
DISASSEMBLY AND PARTS LIST
1-1-4. LCD PANEL and COVER, BOTTOM
1-1. KD-43X Series
KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
REF. No. PART No. DESCRIPTION MARK
1 A-2207-613-A LCM ASSY TPT430U3-EQYSHM.G S1AM
