17
DISASSEMBLY AND PARTS LIST
1-1-5. MISCELLANEOUS
KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
REF. No. PART No. DESCRIPTION MARK
1 1-493-312-12 REMOTE COMMANDER(RMT-TX300U) FOR UC2/LA1 region
1-493-313-12 REMOTE COMMANDER(RMT-TX300B) FOR CO1/LA8/AR4 region
2 1-846-425-43 CORD SET POWER-SUPPLY FOR UC2/CO1/LA1 region
1-846-428-43 CORD SET POWER-SUPPLY FOR LA8 region
1-846-426-43 CORD SET POWER-SUPPLY FOR AR4 region
3 4-734-616-01 MANUAL FOR UC2 region
4-734-617-01 MANUAL FOR LA1/LA8 region
4-734-620-01 MANUAL FOR AR4/CO1 region
1-1. KD-43X Series
To Next Page
