21
DISASSEMBLY AND PARTS LIST
1-2-4. LCD PANEL and COVER, BOTTOM
1-2. KD-49X Series
KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
REF. No. PART No. DESCRIPTION MARK
1 A-2207-614-A LCM ASSY TPT490U2-QUB8A.K S89P0F
