44
1-18. How to assemble the Rattle-Noise Countermeasure(KD-43X SERIES)
1-18-1.Stick HIMERON on the of Hex-screws.
Item SONY PN Part Name Description(L*W )(mm) Qty Remark
1 4-695-529-01 HINERON
45mm*10mm*0.25mm
4 BY SONY
CAUTION: MUST APPLY HIMERON TAPE before assemble Panel if NOT AVAILABLE
1. Make the Himeron roll
the vase and the top of the
vase could not be covered
KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
For this portion, Himeron tape will be attached by SONY
To Next Page
