KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
45
For this portion, Himeron tape will be attached by SONY
1-18-2.Stick HIMERON on the Panel.
2.Silica gel aimed at the convex hull, Attached it in the middle of the
convex hull
3. nonwoven fabric on the panel iron edge, along the panel
below the heavy side attached to the right, attached with a heavy
side, not beyond the heavy side
Item Part Name SONY PN SPEC(L*W*T) Qty Position REMARK
2 RUBBER
4-737-472-
D7.8mm*T2.5mm 5 Panel Top
BY SONY
3 HEMIRON
4-739-888-01 938mm*8mm*0.5mm 1 Panel Top Side
To Next Page
