DIAGRAMS
3-3. CIRCUIT BOARDS LOCATION
3-3-1. KD-43X SERIES
KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
A BOARD
POWER BOARD
H BOARD
WIFI BOARD
KEY BOARD
