- 15 -
Additional information
26
Teaching the remote control*
To eliminate the amount of remote controls you need, this remote control has a
learning feature. Once set up as explained below, it can be used in place of your
other remote controls.
Erasing the last learned function
Erasing all the learned functions
1.
Press and hold the
.
button for approximately six seconds, until the
‘AUX’ light flashes.
2.
Press the button on which you wish to store a learned function on. The
VCR, TV, DVD and AUX lights flash in order.
The following buttons can be used to store learned functions:
VIDEO I/1 button Numbered buttons
V, v, B, b buttons OK button
Coloured buttons Menu button
Prog+/- buttons
3.
Position the other remote control as shown. Press the button that you
wish to teach your TV remote control. The VCR, TV, DVD and AUX lights
illuminate at the same time when a function has been learned and stored.
4.
Repeat steps 2 and 3 to learn other functions.
5.
Press the
.
button to finish.
1.
Press and hold the
.
button for approximately six seconds, until the
‘AUX’ light flashes.
2.
Press the % button to erase the last learned function.
3.
Press the
.
button to return to normal operation.
1.
Press and hold the
.
button for approximately six seconds, until the
‘AUX’ light flashes.
2.
Press the % and
.
buttons to erase all learned functions.
3.
Press the
.
button to return to normal operation.
TV remote control
Other remote control
*The functions learned may be lost if weak
batteries are not replaced immediately.
2-10cm
Additional information
27
:
Specifications
TV System B/G/H, DK, I, L
Colour System PAL,SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12, R21-R69
Picture Tube KV-32HQ100K: Super Fine Pitch FD Trinitron Approx. 82cm
KV-36HQ100K: Super Fine Pitch FD Trinitron Approx. 91cm
Sound Output Left/Right: 2x20W (music power), 2x10W (RMS)
Subwoofer: 1x30W (music power), 1x15W (RMS)
Power
Consumption
KV-32HQ100K: Approx. 160W
KV-36HQ100K: Approx. 160W
Dimensions
(w x h x d)
KV-32HQ100K: Approx. 1015 x 575 x 590mm
KV-36HQ100K: Approx. 1100 x 625 x 620mm
Weight KV-32HQ100K: Approx. 68kg
KV-36HQ100K: Approx. 78kg
Rear Terminals 21-pin Euro connector (CENELEC standard) including audio/video input,
RGB input, TV audio/video output.
21-pin Euro connector (CENELEC standard) including audio/video input,
RGB input, TV audio/video output
21-pin Euro connector (CENELEC standard) including audio/videoinput,
S-video input, selectable audio/video output.
21-pin Euro connector (CENELEC standard) including audio/videoinput,
S-video input.
RF In
Audio output - RCA phono jacks
Side Terminals Video input - phono jack
S video input - 4 pin
DIN
Audio inputs - phono jacks
Headphones jack - minijack stereo
Accessories
Supplied
RM-940 remote control (1)
IEC designated size AA battery (2)
Design and specification are subject to change without notice
