Sony LX40 - Chassis Section

7-2
7-1-2. CHASSIS SECTION
51
52
56
#1
not supplied
not supplied
#1
#1
53
54
54
54
54
54
55
not supplie
d
54
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51 3-959-383-01 BASE (R), MD
52 3-987-076-11 PANEL, REAR
53 A-6713-826-A MA-405 COMPLETE PC BOARD
(LX50:CL,CS)
* 53 A-6713-827-A MA-405 COMPLETE PC BOARD
(LX60S/LX70S:MX,PA,PC,VZ)
* 53 A-6713-828-A MA-405 COMPLETE PC BOARD
(LX70S:CL,CS)
* 53 A-6713-829-A MA-405 COMPLETE PC BOARD
(LX40/LX50:MX,PA,PC,VZ)
54 3-970-608-21 SUMITITE (B3), +BV
55 1-791-857-11 CABLE, FLAT (FMD-21)
56 X-3950-107-1 PANEL ASSY, REAR
#1 7-685-648-79 SCREW + BVTP 3 x 12 TYPE2 IT-3
