2-2
2-3. REAR PANEL
2-4. MA-405 BOARD
Hooks
Hooks
Hooks
Hooks
2 Rear panel
(Engaged by the seven hooks)
1 POWER code stopper
2 MA-405 board with
mechanism deck
1 Six screws
(Sumitite (B3) +BV)
