Exterior dimensions
Units: mm
Rack mounting
This recorder can be rack mounted on a standard EIA 19-
inch rack. After removing the four feet, the unit can be
mounted in a rack.
To remove the for feet attached to the bottom of the
recorder, use a pair of tweezers or similar tool to remove
the plastic pin set at the center of each foot. The feet can be
detached after the pin has been removed.
