43
MDX-CA680/CA680X
Pin No. Pin Name I/O Description
91 SRDR O Sled servo drive PWM signal (–) output to the BH6518FS (IC303)
92 SFDR O Sled servo drive PWM signal (+) output to the BH6518FS (IC303)
93 SPRD O Spindle servo drive PWM signal (–) output to the BH6518FS (IC303)
94 SPFD O Spindle servo drive PWM signal (+) output to the BH6518FS (IC303)
95
FGIN
I
96
TEST1 I
97
TEST2 I
98
TEST3 I
99 DVSS — Ground terminal (digital system)
100 EFMO O EFM signal output terminal when recording mode Not used (open)
* I (A) for analog input, O (3) for 3-state output, and O (A) for analog output in the column I/O.
Input terminal for the test (fixed at “L”)
