53
MDX-CA680/CA680X
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY
KEY BOARD
**********
1-694-780-11 CONDUCTIVE BOARD, CONNECTION
* 3-223-797-01 PLATE (LCD), LIGHT GUIDE
* 3-223-798-01 HOLDER (LCD)
* 3-223-799-01 PLATE (LCD), GROUND
* 3-223-800-01 ILLUMINATOR (LCD)
3-231-770-01 SPACER (WINDOW)
< CAPACITOR >
C952 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C953 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C956 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C961 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C962 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C971 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-794-065-22 PLUG, CONNECTOR 14P
< DIODE >
D902 8-719-056-82 DIODE UDZ-TE-17-6.2B
D903 8-719-056-82 DIODE UDZ-TE-17-6.2B
D904 8-719-056-82 DIODE UDZ-TE-17-6.2B
D906 8-719-056-93 DIODE UDZ-TE-17-18B
D908 8-719-976-99 DIODE DTZ5.1B
D971 8-719-056-82 DIODE UDZ-TE-17-6.2B
< IC >
IC900 8-759-826-21 IC LC75874W
IC971 8-749-012-25 IC RS-170-TU
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-295-11 DISPLAY PANEL, LIQUID CRYSTAL (CA680)
LCD901 1-804-295-21 DISPLAY PANEL, LIQUID CRYSTAL (CA680X)
< LED >
LED900 8-719-061-16 LED CL-190SR-CD-T (KEY ILLUMINATION)
(CA680X)
LED900 8-719-082-91 LED CL-165Y/FG-D-T (KEY ILLUMINATION)
(CA680)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
LED901 8-719-061-16 LED CL-190SR-CD-T (KEY ILLUMINATION)
(CA680X)
LED901 8-719-082-91 LED CL-165Y/FG-D-T (KEY ILLUMINATION)
(CA680)
LED902 8-719-082-80 LED LOM670 (MBP) (US)
LED902 8-719-082-81 LED LBM676 (MBP) (AEP, UK)
LED903 8-719-082-80 LED LOM670 (D-BASS) (US)
LED903 8-719-082-81 LED LBM676 (D-BASS) (AEP, UK)
LED905 8-719-078-19 LED LWA673-R1S2*1 (LCD BACK LIGHT)
LED906 8-719-078-19 LED LWA673-R1S2*1 (LCD BACK LIGHT)
LED909 8-719-078-19 LED LWA673-R1S2*1 (LCD BACK LIGHT)
LED910 8-719-078-19 LED LWA673-R1S2*1 (LCD BACK LIGHT)
LED913 8-719-061-16 LED CL-190SR-CD-T (KEY ILLUMINATION)
(CA680X)
LED913 8-719-082-91 LED CL-165Y/FG-D-T (KEY ILLUMINATION)
(CA680)
LED914 8-719-061-16 LED CL-190SR-CD-T (KEY ILLUMINATION)
(CA680X)
LED914 8-719-082-91 LED CL-165Y/FG-D-T (KEY ILLUMINATION)
(CA680)
< SWITCH >
LSW901 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (OFF)
(CA680X)
LSW901 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (OFF)
(CA680)
LSW902 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (MENU)
(CA680X)
LSW902 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (MENU)
(CA680)
LSW903 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(CA680X)
LSW903 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(CA680)
LSW904 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (MODE)
(CA680X)
LSW904 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (MODE)
(CA680X)
LSW905 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (SOUND)
(CA680X)
LSW905 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (SOUND)
(CA680X)
LSW906 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (ENTER)
(CA680X)
LSW906 1-786-112-11 SWITCH, KEY BOARD (WITH LED) (ENTER)
(CA680)
