Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
59
MDX-CA680/CA680X
R672 1-216-809-11 METAL CHIP 100 5% 1/16W
R673 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R700 1-216-809-11 METAL CHIP 100 5% 1/16W
R701 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R702 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R707 1-216-049-11 RES-CHIP 1K 5% 1/10W
R710 1-216-809-11 METAL CHIP 100 5% 1/16W
R711 1-216-809-11 METAL CHIP 100 5% 1/16W
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R713 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R714 1-249-413-11 CARBON 470 5% 1/4W
(CA680X)
R714 1-249-409-11 CARBON 220 5% 1/4W
(CA680)
R715 1-216-809-11 METAL CHIP 100 5% 1/16W
R716 1-216-809-11 METAL CHIP 100 5% 1/16W
R717 1-216-809-11 METAL CHIP 100 5% 1/16W
R718 1-216-809-11 METAL CHIP 100 5% 1/16W
R719 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S701 1-771-540-11 SWITCH, PUSH (1 KEY) (NOSE DETECT)
S702 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR >
TH600 1-801-792-21 THERMISTOR, POSITIVE
< TUNER UNIT >
TU10 A-3282-061-A TUNER UNIT (TUX-020)
< VIBRATOR >
X51 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
X501 1-781-294-21 VIBRATOR, CRYSTAL (18.432MHz) (US)
X501 1-795-134-11 VIBRATOR, CRYSTAL (18.432MHz) (AEP, UK)
X502 1-567-098-71 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
A-3326-727-A SENSOR BOARD, COMPLETE
************************
For the parts on the SENSOR board, replace the entire mounted board.
**************************************************************
* A-3326-729-A SERVO BOARD, COMPLETE
***********************
< CAPACITOR >
C10 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C11 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C102 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C201 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C202 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C306 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C308 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C309 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C310 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C311 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C314 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C315 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C318 1-104-852-11 TANTALUM CHIP 22uF 20% 6.3V
C319 1-104-852-11 TANTALUM CHIP 22uF 20% 6.3V
C320 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C321 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C325 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C326 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C327 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C328 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C329 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C333 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C336 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C342 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C343 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C344 1-104-852-11 TANTALUM CHIP 22uF 20% 6.3V
C345 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C346 1-104-852-11 TANTALUM CHIP 22uF 20% 6.3V
C347 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C349 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C350 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C351 1-104-852-11 TANTALUM CHIP 22uF 20% 10V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C353 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C356 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C357 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C358 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C359 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C362 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C363 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C401 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C501 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C506 1-104-852-11 TANTALUM CHIP 22uF 20% 10V
C510 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
MAIN SENSOR SERVO
